Pos. Item no. Description Part marking
1 00373684-02 SAFETY HOOD RIGHT SIDE/CS
2 00373781-02 SCREEN/SAFETY HOOD/CS
3 00373685-02 SAFETY HOOD LEFT SIDE/CS
4 00373781-02 SCREEN/SAFETY HOOD/CS
5 00373890-01 STAY 1 /CS COMPL. ASSEMBLED
6 00373677-02 STAY 1/CS
7 00319359-02 BUSHING SPARE PART
8 00845026-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 12-8.8
9 00319360-01 AXIS 1
10 00322791-02 PEDESTAL Spare Part
11 00095368-01 SET SCREW
12 00314036-01 SHIM SPARE PART
13 00373891-01 STAY 2 /CS COMPL. ASSEMBLED
14 00373678-02 STAY 2/CS
15 00319359-02 BUSHING SPARE PART
16 00845026-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 12-8.8
17 00319360-01 AXIS 1
18 00322792-02 BEARING BLOCK 2 Spare Part
19 00095368-01 SET SCREW
20 00314036-01 SHIM SPARE PART
21 00373892-01 STAY 3 /CS COMPL. ASSEMBLED
22 00373679-02 STAY 3/CS
23 00319359-02 BUSHING SPARE PART
24 00845026-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 12-8.8
25 00321177-01 AXIS 2
26 00322791-02 PEDESTAL Spare Part
27 00095368-01 SET SCREW
28 00314036-01 SHIM SPARE PART
29 00373893-01 STAY 4 /CS COMPL. ASSEMBLED
30 00373680-02 STAY 4/CS
31 00319359-02 BUSHING SPARE PART
32 00845026-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 12-8.8
