Pos. Item no. Description Part marking
03038870S01 BASE PORTAL SIPLACE HS60-D *
1 00328637-03 GANTRY PROCESSED HS50
2 03038049-01 HEAD MOUNT - PROCESSED HS60-D
3 00330938-02 DEFLECTION UNIT X SPARE PART
4 03044507-01 BUFFER COMPL.
5 00301040-01 ELASTOMER SPRING 25*10,5*50
(90 SHORE A)
SPARE PART
6 00305650-01 SLEEVE SPARE PART
7 03045111-01 DIN912-M8 X 20-A2-70
8 00329316-02 SCALE X-ACHSE F. S 50 SPARE PART
9 03040614-01 DRIVE UNIT X-Y (D4I)
10 03040613-01 MOTOR MOUNT WITH QUICK
RELEASE FASTENER
11 03040318-01 MOTOR MOUNT
12 00337340S01 QUICK-RELEASE FASTENER 4.3/3 SPARE PART
13 00335794-02 CLAMPING PLATE
14 00349452-01 SUPPORT BOLT *
15 03045649-01 DIN 125-A 8,4-140HV-A2
16 03046846-01 DIN 934 - M 8 - 8.8, ZINC-C.DSP
17 03046829-01 DIN912-M6 X 20-8.8, ZINC-C.DSP
18 00333167S03 MOTOR UNIT X-AXIS SPARE PART
19 00353411-01 SUPPORT ROLLER 20*47*25
20 03090958S01 LINEAR MOTOR PRIMARY SECTION Y
AXIS
*
21 03046827-01 DIN912-M5 X 20-8.8 ZINC C.TFP
22 03039135-01 MOTOR SUPPORT INSULATING
PLATE
23 00329490-01 DISTANCE BOLT
24 00364612-01 SYNCHRONISING DISC, LONG,
COMPL.
SPARE PART
25 00364613-01 SYNCHRONISING DISC, SHORT,
COMPL.
SPARE PART
26 00332819-01 RECIRCULATING BALL UNIT 12 B
27 00329478-01 WRENCH TOOL
28 00329485-01 RING SPANNER TOOL
29 00331076-02 TOOTHED BELT SYN. 50ATS5/1205
E9/11 Z+S
WEAR PART
