1-28 N67xx DUT Power Supply Installation Updating the Configuration Files The power supply c onnections must be defi ned in the system and standar d config files: \I3070_ICT_R OOT\diagnostics\ th1\config \I3070_ICT_R OOT…

N67xx DUT Power Supply Installation 1-27

Module 0, Utility Card channel 7 or 7-8 12 ps12

Module 0, Utility Card channel 8 13 ps13

Module 1, Utility Card channel 7 or 7-8 15 ps14

Module 1, Utility Card channel 8 16 ps15

Module 2, Utility Card channel 7 or 7-8 18 ps16

Module 2, Utility Card channel 8 19 ps17

Module 3, Utility Card channel 7 or 7-8 20 ps18

Module 3, Utility Card channel 8 30 ps19

If a supply is split between two modules, use the device file

address and GPIB address of the lower numbered module.

Table 1-8 DUT Power Supply Addressing (continued)

Power Supply Connection GPIB Address Device File (in /dev/)

1-28 N67xx DUT Power Supply Installation

Updating the Configuration Files

The power supply connections must be defined in the system and standard config

files:

\I3070_ICT_ROOT\diagnostics\th1\config

\I3070_ICT_ROOT\standard\config

Use the supplies statement.

supplies <type> <#> asru channel <#>

• The supplies type can be ps6751, ps6752, ps6746, or ps6773 depending on

which power supply was installed.

• The first number or range of numbers gives the testhead supply number

(

1 through 24). The numbering of the supplies in the supplies statement is

arbitrary. The software will accept any mapping of supply numbers to modules.

However, you cannot assign a power supply number more than once in a

testhead. If the customer has more than one system, make the new

supplies

statement compatible with the other system.

• The second number or range of numbers gives the ASRU Card DUT channel.

This must match the physical connection of the supply to the ASRU card. You

cannot assign a channel number (1 through 6) more than once in a module.

The following table shows the default and alternate power supply mapping for each

module and the proper syntax for each type of power supply.

After the

config files have been updated, compile both files.

If the new power supply has been placed on a wrong channel,

you will get a compiler error.

N67xx DUT Power Supply Installation 1-29

Table 1-9 Default and alternative power supply mapping

Module 2

!supplies ps6751 5 to 8 asru channels 1 to 4

supplies ps6752 5 to 6 asru channels 1 to 4

!supplies ps6751 19 to 20 asru channels 5 to 6

!supplies ps6752 19 asru channels 5 to 6

supplies ps6746 19 asru channels 5

supplies ps6746 20 asru channels 6

!supplies ps6773 19 asru channels 5 to 6

Module 0

supplies ps6751 13 to 16 asru channels 1 to 4

!supplies ps6752 13 to 14 asru channels 1 to 4

!supplies ps6751 23 to 24 asru channels 5 to 6

supplies ps6752 23 asru channels 5 to 6

!supplies ps6746 23 asru channels 5

!supplies ps6746 24 asru channels 6

!supplies ps6773 23 asru channels 5 to 6

Module 3

supplies ps6751 1 to 4 asru channels 1 to 4

!supplies ps6752 1 to 2 asru channels 1 to 4

supplies ps6751 17 to 18 asru channels 5 to 6

!supplies ps6752 17 asru channels 5 to 6

!supplies ps6746 17 asru channels 5

!supplies ps6746 18 asru channels 6

!supplies ps6773 17 asru channels 5 to 6

Module 1

supplies ps6751 9 to 12 asru channels 1 to 4

!supplies ps6752 9 to 10 asru channels 1 to 4

!supplies ps6751 21 to 22 asru channels 5 to 6

!supplies ps6752 21 asru channels 5 to 6

supplies ps6746 21 asru channels 5

supplies ps6746 22 asru channels 6

!supplies ps6773 21 asru channels 5 to 6
