Recognition Error ID Description of Recognition Error
02200802 Totals of "the number of form" is not sucient.
02200803 No detection is set in all "Form Insp Condtn" text boxes.
02200804 "Direction of shape" of the edge shape is all parallel.
02200805 "Width of shape" is small.
02200806 "Height of shape" is small.
02200807 "Shape pitch" is small.
02200808 The interval of shape is narrow.
02200809 There is a lot of "Number of shape".
0220080a The total of the edge shape is little.
0220080b The setting of the recognition level is improper otherwise, unnecessary shape
was registered.
02200851 "Graphic number of group" is small.
02200901 "Mold Size Tolerance X" is larger than "Mold Size X".
02200902 "Mold Size Tolerance Y" is larger than "Mold Size Y".
02200903 "Outward Length Tolerances" are larger than "Outward Length".
02200904 "Polarity Inspection Position" out of "Mold Size"
02200905 Selected algorithm is improper.
02200906 Failed in automatic selection of algorithm.
02200907 Dierent View in "View set" is set
02200908 "Range of both sides decision inspection" is small.
02200909 "Position of both sides decision inspection" is not within a size of a component.
0220090a [Pick-up pos. correction] is being set although the cmpnt size is large.
0220090b [Input direction] is set by 45(deg) although the cmpnt size is large.
0220090c [Pick-up angle] is being set although the cmpnt size is large.
0220090d Input direction is not the width's direction although the cmpnt size is large.
02200a01 The nozzle cannot be used because the method of illuminating is dierent from
lighting method of the component library.
02200a02 "Flux spread conrmation" can not be performed because "electrode width" is
small.
02200a03 Cannot do "Flux spread conrmation" because "Electrode space" is narrow.
02200b01 "Window Size" is smaller than "BarCode Size".
02200c01 It is o the subject of the division recognition processing(too large component
size)
02200c02 It is o the subject of the division recognition processing(decision inspection)
02200000 Others.
02300000 Recognition Communication Procedure Error.
02400001 An error occurred during data transfer between recognition and counter boards.
02400002 An error occurred during data transfer between recognition and lighting control
boards.
02400003 Lighting control board self-diagnostic abnormalities
02400004 Lighting control board self-diagnostic abnormalities
02400005 Lighting control board self-diagnostic abnormalities
02400101 The Comp. recognition lighting of beam 1 did not light.
02400102 The Comp. recognition lighting of beam 2 did not light.
3. Recognition Error IDs and Remedial Procedures
4OM-1840
4-1-71604-001
Recognition Error ID Description of Recognition Error
02400103 The Comp. recognition lighting of beam 3 did not light.
02400104 The Comp. recognition lighting of beam 4 did not light.
02400301 There is the dierence with settings for PEC Recognition Camera1.
02400302 There is the dierence with settings for PEC Recognition Camera2.
02400000 Others.
02900000 Others.
02900001 Image Acquiring in was interrupted.
02900002 The eye match was interrupted.
02900003 Failed in a division calculation of placement coordinate teaching.
02900101 Image data le can't be saved.
02900102 Image data le can't be saved.
02900103 Image data le can't be saved.
02900104 Image data le can't be saved.
02900105 Image data le can't be saved.
02900106 Data error.
02900107 Exception error.
02900108 There is no empty area enough for the disk.
02d00000 Error in Recognition internal.
02e00000 Error in Recognition internal.
12000000 Error in Recognition internal.
05000000 Others.
05000001 Component was not found.
05100001 Component was not detected.
05100101 The detection window of the length position of lead sequence can't be set up.
05100102 The length position of a lead sequence can't be detected.
05100103 Impossible to set the window for lead detection at the corner.
05100104 The lead edge of a corner can't be detected.
05100105 The lead of a corner can't be detected.(Cmpnt Angle inclined)
05100106 few lead numbers of the detected corner than the set-up.
05100107 The distance during the lead of the detected corner is poor.(Cmpnt Angle
inclined)
05100108 The angle during the lead of the detected corner is poor.
05100201 No Electrode(ball) Detected.
05100601 Shape (L type) cannot be detected.
05100602 Shape (U type) cannot be detected.
05100603 Shape (edge) cannot be detected.
05100604 Shape (rectangle) cannot be detected.
05100605 Shape (oval) cannot be detected.
05100000 Others.
05200101 More than two corners of a component are hidden by the protruded nozzle.
05200102 Corner not detected.
05200201 Some edges cannot be detected because they are hidden by the nozzle.
05200202 Edge not detected.
05200203 Some edges cannot be detected because they are hidden by the nozzle.
3. Recognition Error IDs and Remedial Procedures
4OM-1840
4-1-81604-001
Recognition Error ID Description of Recognition Error
05200204 Edge not detected.
05200301 Angle calculation impossible.
05200401 Impossible to set the window for lead detection.
05200402 The length position of a lead can't be set up.(Cmpnt Angle inclined)
05200403 The detected number of leads is smaller than the set value.
05200404 The detected number of leads is larger than the set value.
05200405 The lead length cannot be detected.
05200501 Electrode(ball) which is in agreement with data was undetectable.
05200502 Since a sucient number of Electrode(ball) were undetectable, it cannot position.
05200601 Shape (L type) cannot be detected.
05200602 Shape (U type) cannot be detected.
05200603 Shape (edge) cannot be detected.
05200604 Shape (rectangle) cannot be detected.
05200605 Shape (oval) cannot be detected.
05200606 There is shape that cannot be detected as in the shade of nozzle etc.
05200607 The Shape corresponding to data was not able to be detected.
05200000 Others.
05800001 The pick-up position has deviated greatly.
05800002 The pick-up position has deviated greatly in X direction.
05800003 The pick-up position has deviated greatly in Y direction.
05800004 The pick angular skew is big.
05800101 Component outward length X is incorrect.
05800102 Component outward length X is shorter than the tolerance.
05800103 Component outward length X is longer than the tolerance.
05800104 Component outward length Y is incorrect.
05800105 Component outward length Y is shorter than the tolerance.
05800106 Component outward length Y is longer than the tolerance.
05800107 Component outward length X or Y is incorrect.
05800108 Component outward length X or Y is shorter than the tolerance.
05800109 Component outward length X or Y is longer than the tolerance.
05800201 The number of leads is small.
05800202 The number of leads is large.
05800203 The lead width is shorter than the tolerance.
05800204 The lead width is longer than the tolerance.
05800205 Gap of the width direction of a lead is larger than a permissible value.(Cmpnt
Angle inclined)
05800206 Gap of the length direction of a lead is larger than a permissible value.
05800207 The detected lead length direction positions dier greatly.
05800208 The lead length is shorter than the tolerance.
05800209 The lead length is longer than the tolerance.
05800301 Electrode(ball) length is incorrect.
05800302 Electrode(ball) position is larger than a permissible value.
05800303 Electrode(ball) which must not exist existed.
05800401 A shape positional gap is larger than a permissible value.
3. Recognition Error IDs and Remedial Procedures
4OM-1840
4-1-91604-001
