Electric Circuit Diagram (7/7)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-005721A CABLE ASSY-AC RELAY POWER 1 SM471_PW105
2 AM03-005462B CABLE ASSY-R RIGHT FEEDER BASE PWR 2 SM471_FD007
3 AM03-005479A CABLE ASSY-RY3_RY5_T7L 1 SM471_PW207
4 AM03-005461B CABLE ASSY-R LEFT FEEDER BASE PWR 2 SM471_FD006
5 AM03-005460B CABLE ASSY-F RIGHT FEEDER BASE PWR 2 SM471_FD005
6 AM03-005459B CABLE ASSY-F LEFT FEEDER BASE PWR 2 SM471_FD004
7 AM03-005479A CABLE ASSY-RY3_RY5_T7L 1 SM471_PW207
8 AM03-005506A CABLE ASSY-GENERAL_PW_RELAY 1 SM471-PW032
9 AM03-005507A CABLE ASSY-FEEDER_PW_RELAY 1 SM471-PW033
10 AM03-005458B CABLE ASSY-R FDR PWR RELAY CABLE ASSY 2 SM471_FD003
11 EP02-000588A FEEDER CN7 EXT CABLE ASSY 1 SM411N-FD001
12 AM03-005456A CABLE ASSY-F FDR PWR RELAY CABLE ASSY 2 SM471_FD002
13 AM03-005508A CABLE ASSY-RELAY_PW_SUPPLY 1 SM471-PW135
14 AM03-900148 RELAY_CONNECT_CABLE_ASSY SM41-PW034 1 SM41-PW034
15 AM03-005463A CABLE ASSY-24V POWER EXT 2 SM471_FD008
Page
HANWHA TECHWIN
204
SM471
PLUS
Articles of Consumption
Page
HANWHA TECHWIN
205
SM471
PLUS
Articles of Consumption
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Reference
1 MC05-900057 BELT_WORK MAM-5P-1550-6W
2 MC05-900059 BELT_SHUTTLE_1650 MAM-5P-1169-6W
3 MC05-900074 BELT_SHUTTLE_LONG MAM-5P-1500-6W
4 HP04-001258A FILTER,AIR-ELENMENT[AF30P-060S]
5 HP04-001259A FILTER,OIL-ELENMENT[AFM30P-060S]
6 HP04-900036 SUCTION_FILTER VYF44-M-50M
7 EP10-900438 FUSE[250V 5A]
8 EP10-900439 FUSE[250V 10A]
9 CM02-000059 GREASE-GADUS_S2 V220 2
10 CM02-000083 GREASE-GREASE_AFE-CA+70_THK;SYNTHETIC,OL
11 CM02-000092 GREASE-FLOIL G-146K
12 J9099107A GREASE GUN
13 J7069038A NIPPLE TIP(CP60L X-FRAME)[J7069038A]
14 HP09-000258 SUPPLY,OIL-GREASE-GUN_MG70_THK
15 CM01-900473 TRI-FLOW [59ML]
16 J90551072A NOZZLE_CN400_ASSY J90551072A
17 J9055134C NOZZLE CN040 ASSY[J9055134C]
18 AM03-900053 CLEANING KIT
