Machine protection D2
Page 15 / 17 18.11.2021
Pos. Item no. Description Part marking
LENGTH 200MM
00335306-02 CABLE HS50: START
/STOP/EMERGENCY-STOP
SPARE PART
00328232-01 SWITCH ELEMENT 3SB3400-0B 1NO
SCREW TER.
SPARE PART
00337636-01 SWITCH ELEMENT 3SB3 / 1S+1OE SPARE PART
30 03045748-03 OPERATOR COVER LEFT, COMPLETE
31 03045740-02 SIDE COVER, LEFT, WELD
32 03090632-01 COUNTER ASSY D-SERIES
33 00349458-01 ON-OFF PUSHBUTTON 3SB3
WT(I)/BL(0)
SPARE PART
34 03025743-02 KEYBOARD HOLDER, OPERATOR
CONSOLE CPL.
SPARE PART
35 03042271-02 DOOR ASSEMBLY, LEFT
36 03039518-01 QUARTER TURN W. DOUBLE BIT
37 03046268-01 HINGE SUPPORT 1, COMPLETE
38 03050056-01 HINGE SUPPORT 2, COMPLETE
39 03046264-01 OPERATOR CONTROL GUIDE, LEFT
40 00334073-01 MUSHROOM PUSHBUTTON 3SB3
RED 40MM
SPARE PART
41 00337636-01 SWITCH ELEMENT 3SB3 / 1S+1OE SPARE PART
03044326-01 CHAIN LINKAGE FITTING B-135-4.5
03044332-01 RESTRAINING CABLE WITH EYE
LENGTH 200MM
03041693-01 CABLE: START,STOP,EMERG.-STOP,
COMP-COUNT
00328232-01 SWITCH ELEMENT 3SB3400-0B 1NO
SCREW TER.
SPARE PART
00337636-01 SWITCH ELEMENT 3SB3 / 1S+1OE SPARE PART
44 03049134-01 COVER COMPONENT COUNTER D-
SERIES
45 03046027-02 SIDE PANEL RIGHT, COMPLETE
46 03046026-02 SIDE PANEL LEFT, COMPLETE
03048715-02 PANEL COVER PLATE S-D,
COMPLETE
47 03045741-03 STATIC HOOD SPARE PART
48 03065795-01 D1/D2 DTC MOVABLE HOOD
ASSEMBLY RIGHT, COMPLETE
49 03046290-01 BAR CODE LABEL RIGHT F-D SPARE PART
Machine protection D2
Page 16 / 17 18.11.2021
Pos. Item no. Description Part marking
50 03066066-01 D2 DTC MOVABLE HOOD LEFT,
COMPLETE
51 03046298-01 BAR CODE LABEL LEFT F-D SPARE PART
52 03066694-01 FAN ASSEMBLY
53 03066669-01 FILTERTRAY 120MM FAN
54 03066670-01 FAN BRACKET R1
55 03076892-01 WIRE GRID FOR 120MM FANS SPARE PART
56 03053515-02 GANTRY FAN, Y-AXIS D1/2
57 03056479-01 AXIAL FAN TYPE 4414FNN
66 03066697-01 REMOVABLE TOP COVER, RIGHT
67 03066698-01 REMOVABLE TOP COVER, LEFT
68 03053081-02 D1/D2 SAFETY COVER
69 03040334-01 MAIN ERROR INDICATOR ASSY/D4 SPARE PART
70 03040333-01 LAMP TUBE
71 03004316-01 CONNECTION ELEMENT INCL.
CLOSING COVER
72 03004318-01 PERMANENT LIGHT ELEMENT
GREEN
73 03004317-01 PERMANENT LIGHT ELEMENT CLEAR
74 03066318-01 LED BULB BA15D BASE YELLOW WEAR PART
75 03066319-01 LED BULB BA15D BASE GREEN WEAR PART
76 03044448-01 MONITOR MOUNT 2 SUB-ASM - HS-
D
03050068-02 ELECTRICAL, D1/D2
77 03050069-01 SAFETY SWITCH COMBINATION,
RIGHT
SPARE PART
78 03046094-01 SWITCH MOUNT RIGHT F-D
79 00335263-02 SWITCH FOR COVER SECTOR 1 TO 4 SPARE PART
80 03050070-01 SAFETY SWITCH COMBINATION,
LEFT
SPARE PART
81 03046093-01 SWITCH MOUNT LEFT F-D
82 00335263-02 SWITCH FOR COVER SECTOR 1 TO 4 SPARE PART
83 03067244-01 GAS SPRING FOR D1/D2 DTC HOOD
RIGHT
SPARE PART
84 03067227-01 GAS SPRING FOR D1/D2 DTC HOOD
LEFT
SPARE PART
85 03051917-01 GAS SPRING 6/15 SPARE PART
86 00373984-03 KEYBOARD, GERMAN LAYOUT Spare Part
