Digital Multimeters — Tektronix DMM4020
AC Current
The following A
C current specifications are for sinusoidal signals with amplitudes
greater than 5% of range. For inputs from 1% to 5% of range, add an additional
error of 0.1% of range.
Characteristic
Description
Input Protection
Tool-accessible 11 A / 1000 V and 440 mA / 1000 V
fuses
Measurement Method
AC-coupled true RMS
Shunt Resistance 0.01 Ω for 2 A and 10 A ranges
1 Ω for 20 mA and 200 mA
AC Filter Bandwidth
20 Hz - 100 kHz
Maximum C rest Factor 3:1 at Full Scale
Additional Crest Factor
Errors (<100 Hz)
Crest Factor 1-2, 0.05% of full scale
CrestFactor2-3,0.2%offullscale
Only applies to non-sinusoid signals
Input Characteristics
ResolutionRange
Full Scale
(5½ Digits)
Slow
Medium Fast
Burden Voltage
20 mA 19.9999 mA 0.1 μA1μA1μA <0.05 V
200 mA 199.999 mA 1 μA10μA10μA<0.5V
2 A 1.99999 A 10 μA100μA100μA<0.1V
10 A 10.0000 A 100 μA1mA 1mA<0.5V
Accuracy
Uncertainty*
3
90 d ays 1 year
Range Frequency
23 °C ± 5 °C 23 ° C ±5 °C
Temperature C oef ficien t/°C
Outside 18 - 28 °C
20 Hz - 45 Hz 1 + 0.05 1.25 + 0.06 0.015 + 0.00520 mA
45 Hz - 2 kHz 0.25 + 0.05 0.3 + 0.06 0.015 + 0.005
20 Hz - 45 Hz 0.8 + 0.05 1 + 0.06 0.015 + 0.005200 mA
45 Hz - 2 kHz 0.25 + 0.05 0.3 + 0.06 0.015 + 0.005
20 Hz - 45 Hz 1 + 0.05 1.25 + 0.06 0.015 + 0.0052A
45 Hz - 2 kHz 0.25 + 0.05 0.3 + 0.06 0.015 + 0.005
20 Hz - 45 Hz 1 + 0.1 1.25 + 0.12 0.015 + 0.00510 A
45 Hz - 2 kHz 1 + 0.1 0.5 + 0.12 0.015 + 0.005
*
3
Uncertainty given as ±(% of reading + % of range).
www.tektronix.comdmm 9
Datasheet
Frequency
Characteristic Description
Gate Time
131 ms
Measurement
Method
AC-coupled input using the AC voltage
measurement function
Settling
Considerations
When measuring frequency after a DC offset
voltage change, errors may occur. For the most
accurate measurement, wait up to 1 second to allow
input-blocking RC time constant to settle
Measurement
Considerations
To minimize measurement errors, shield inputs
from extern al noise when measuring low-voltage,
low-frequency signals
Input Characteristics
Uncertainty
90 d ays 1 year
Range Frequency
23 °C ± 5 °C 23 ° C ±5 °C
Temperature C oef ficien t/°C
Outside 18 - 28 °C
20 Hz - 2 kHz 0.01 + 0.002 0.01 + 0.003 0.002 + 0.001
2 kHz - 20 kHz 0.01 + 0.002 0.01 + 0.003 0.002 + 0.001
20 kHz - 200 kHz 0.01 + 0.002 0.01 + 0.003 0.002 + 0.001
100mVto750V*
4, 5
200 kHz - 1 MHz 0.01 + 0.004 0.01 + 0.006 0.002 + 0.002
*
4
Input >100 mV.
*
5
Limitedto8×10
7
VHz.
Continuity
Characteristic
Description
Continuity Threshold 20 Ω
Test Current
1mA
Response Time
100 S/s with audible tone
Rate Fast
Maximum Reading
199.99 Ω
Resolution
0.01 Ω
Diode Test
Characteristic
Description
Response Time
100 S/s with audible tone
Rate Fast
Maximum Reading 1.9999 V
Resolution 0.1 mV
10 www.tektronix.comdmm
Digital Multimeters — Tektronix DMM4020
Ordering Information
Models
Model Description
DMM4020 5.5 Digit Multimeter
DMM4020 Inclu
des: Meter, TL710 Test Leads, Line Cord, Statement of Cal
Practices (O
rder option D1 for traceable calibration certificate and data report),
Safety and In
stallation Instructions including Warranty Statement, CD-ROM with
User Manual (
English, French, Italian, German, Spanish, Simplified Chinese,
Traditional
Chinese, Korean, Russian, Japanese) and Connectivity Information,
RS-232 to USB
Adapter Cable, National Instruments LabVIEW SignalExpress™
Tektronix Ed
ition, Limited Edition Software.
Please spec
ify power plug when ordering.
Instrument Options
Power Plug Options
Option
Description
Opt. A0
North America
Opt. A1
Universal Euro
Opt. A2
United Kingdom
Opt. A3
Australia
Opt. A5 Switzerland
Opt. A6
Japan
Opt. A10 China
Opt. A11
India
Opt. A12
Brazil
Opt. E1
Euro and UK power cords
Service Options*
6
Option
Description
Opt. CA1 Provides a single calibration event or coverage for the
designated calibration interval, whichever comes first
Opt. D1 Provides traceable calibration certificateanddatareport
Opt. R5 Repair Service 5 Years (including warranty)
*
6
Test Leads and accessories are not covered by the DMM warranty and Service Offerings. Refer to the
datasheet of each Test Lead and accessory model for its unique warranty and calibration terms.
Recommended Accessories and Software
Accessory Description
Calibration Manual
077-0365-xx
196-3520-xx
Premium Test Leads (replacement/spare for TL710)
TL705
2×4 Wire Ohm 1000 V Precision Test Lead
TL725
2×4 Wire Ohm SMD Test Tweezers
ACD4000 Soft Transit Case
HCTEK4321 Hard Carrying Case
RMU2U
Rackmount Shelf Kit for 1 or 2 Units
013-0369-xx
Calibration Fixture 4-terminal short
196-3520-00 TL710 Premium Test Lead
SIGEXPTE NI LabVIEW SignalExpress Tektronix Edition Software –
Full Version
Tektronix is registered to ISO 9001 and ISO 14001 by SRI Quality System Registrar.
Product(s) complies with IEEE Standard 488.1-1987 and RS-232C.
www.tektronix.comdmm 11
