MEMO
MODEL TCM-3700-2
0109-001
196
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-2
75 630 069 5915 CIRCUIT PROTECTOR 2 CB202, CB203 739BC-01D-041
76 630 091 1909 CIRCUIT PROTECTOR 1 CB201 739BC-01D-075
79 630 053 8601 EM-CONTACTOR 1 MC13 739BC-01D-027
80 630 049 3672 BRACKET,WIRING 3 739BC-01D-026
82 411 119 2104 WASHER V 4X9X0.8 3 FW4 F
83 411 008 1706 WASHER SPR 4 3 SW4 F
84 411 043 5004 SCR PAN 4X8 3 M4X8 PAN
85 630 049 2200 EM-CONTACTOR 2 MC2, MC3 739BC-01D-010
85 -1 630 100 1357 COMP,CR 6 739BC-01D-008
86 630 049 3696 TERMINAL 8 739BC-01D-021
87 630 049 3757 ACCESSORY,WIRING 3 739BC-01D-025
88 630 049 3733 ACCESSORY,WIRING 1 739BC-01D-023
90 630 049 3672 BRACKET,WIRING 2 739BC-01D-026
91 630 088 9482 CIRCUIT PROTECTOR 7 CB212-218 739BC-01D-061
92 630 049 3672 BRACKET,WIRING 2 739BC-01D-026
96 630 049 3696 TERMINAL 3 739BC-01D-021
97 630 049 3757 ACCESSORY,WIRING 1 739BC-01D-025
98 630 049 3733 ACCESSORY,WIRING 1 739BC-01D-023
99 630 049 3672 BRACKET,WIRING 1 739BC-01D-026
101 630 001 0220 WASHER 3 BW5
102 411 141 6705 WASHER SPR 5 3 SW5
103 630 000 7756 BOLT,HEX-SCT 3 M5X12
104 411 036 8609 SCR PAN+SW+W 5X12 1
MEMO
MODEL TCM-3700-2
0109-001
198
㔚᳇ᓮㇱ ELECTRICAL SECTION
Fig.11-3 100V 㔚Ḯ Power Supply-100V
41
44
42
43
13
14
15
16
51
52
53
54
55
56
57
58
86
6
87
88
31
35
.
27-1
27
.
28-1
28
.
29-1
29
.
85-1
85
9
8
7
.
75
71
.
32
32
36
34
33
33
36
12
14
15
16
44
30
22
21
22
91
92
93
30
11
7
8
9
14
15
16
76
76
73
72
66
67
68
69
TCM-3700-2
Fig.11-3
93
93
92
92
91
91
5
