All Bondhus ® tools are made with Protanium ® High T orque Steel. Made in the U .S.A. Exclusive MaxT orque ™ ball end on shor t ar m delivers two times the torque of competitor ball ends, at up to a 15° angle. • Exclusiv…
Made in the U.S.A.
7
L-Wrenches
• Assembled from our most popular sets
• Multiple sets per package
• Tip selections include Ball End, TORX
®
,
Hex End, ProHold
®
Tip Ball End, and
MaxTorque™ Ball End
Multi Packs
20399 BLX22GB 22 26937 (.050-3/8”) + 38099 (1.5-10mm) 1
PART# MODEL# PCS CONTENTS QTY LIST
BriteGuard
™
and GoldGuard
™
Ball End
20899 BLX22G 22 37937 (.050-3/8”) + 38099 (1.5-10mm) 1
PART# MODEL# PCS CONTENTS QTY LIST
GoldGuard
™
Ball End
26999 BLX22B 22 16937 (.050-3/8”) + 16999 (1.5-10mm) 1
PART# MODEL# PCS CONTENTS QTY LIST
BriteGuard
™
Ball End
Metric
TORX
®
Inch
69600 BLX22XLCG 22 69637 (.050-3/8”) + 69699 (1.5-10mm) 1
PART# MODEL# PCS CONTENTS QTY LIST
ColorGuard
™
Ball End
14170 BLF16MB 16 16999 (1.5-10mm) + 12587 (Hex Fold Up 2-8mm) 1
PART# MODEL# PCS CONTENTS QTY LIST
BriteGuard
™
Ball End and ProGuard
™
GorillaGrip
®
Fold Ups
69600
26999
14170
20899
20399
26999
14170
TORX® and TORX PLUS® are registered trademarks of Acument Intellectual Properties, LLC.
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.
69600
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.Made in the U.S.A.
Exclusive MaxTorque
™
ball end
on short arm delivers two times
the torque of competitor ball ends,
at up to a 15° angle.
• Exclusive MaxTorque
™
ball end on short
arm allows acess to screw heads located
in tight spaces straight-in or at an angle
• Exclusive MaxTorque
™
ball end delivers
50% more torque than conventional
ball ends
• Exclusive MaxTorque
™
ball end inserts
into screw and works at a 15° angle
• Standard Bondhus ball end on long
arm inserts into screw and works at a
25° angle
• Extra long length provides for greater
torque
Color-Coded
Inch
Metric
Stubby Double Ball End
L-Wrench compared to
our standard Stubby
L-Wrench
Stubby Double Ball End L-Wrenches
25° working angle on long arm
allows tool to work in hard-to-
reach places.
Stubby tools fit in tight spaces where
there is not enough overhead
clearance for a standard hex key.
MaxTorque
™
Ball End
Long Arm Ball End
100°
90°
MaxTorque
™
Ball End
15° angle
Standard Ball End
25° angle
Exclusive MaxTorque
™
ball
end on short arm delivers two
times the torque of competitor
ball ends, at up to a 15° angle
15° angle
MaxTorque
™
Ball End
8
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.
Made in the U.S.A.
Inch
Sets
Metric
67037 SDBLX13XL 13 Extra Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
67099 SDBLX9MXL 9 Extra Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
PART# MODEL# PCS LENGTH CONTENTS QTY LIST
ProGuard
™
fi nish
delivers superior
corrosion protection
• Exclusive MaxTorque
™
Ball End
- on short arm allows access to screw heads
located in tight spaces straight-in or at an angle
- delivers 50% more torque than conventional
ball ends
- inserts into screw and works at a 15° angle
• Standard Bondhus ball end on long arm inserts
into screw and works at a 25° angle
• Extra long length provides for greater torque
L-Wrenches
Stubby Double Ball End L-Wrenches
Yellow=Inch
Red=Metric
67099
SIZE INCH MM INCH MM
.050 3.1 79 0.25 6 67002 5
1/16 3.3 84 0.24 6 67003 5
5/64 3.6 91 0.32 8 67004 5
3/32 3.9 98 0.36 9 67005 5
7/64 4.1 104 0.36 9 67006 5
1/8 4.4 113 0.37 9 67007 5
9/64 4.8 121 0.37 9 67008 5
5/32 5.1 130 0.38 10 67009 5
3/16 5.3 134 0.44 11 67010 5
7/32 5.7 144 0.48 12 67011 2
1/4 6.5 164 0.49 12 67012 2
5/16 7.1 180 0.61 15 67013 2
3/8 7.8 199 0.84 21 67014 2
1.5 3.5 89 0.24 6 67050 5
2.0 3.9 100 0.32 8 67052 5
2.5 4.4 111 0.35 9 67054 5
3.0 4.9 125 0.37 9 67056 5
4.0 5.6 143 0.38 10 67060 5
5.0 6.4 161 0.43 11 67064 2
6 6.8 173 0.50 13 67068 2
8 7.7 194 0.60 15 67072 2
10 8.4 214 0.82 21 67076 2
PART# QTY LIST EA
Singles
EXTRA
LONG
Inch
EXTRA
LONG
Metric
TAGGED/BARCODED
Ball End on
long arm
15° angle
25° angle
MaxTorque
™
Ball End
SIZE INCH MM INCH MM
.050 3.1 79 0.25 4 77002 5
1/16 3.3 84 0.24 4 77003 5
5/64 3.6 91 0.32 7 77004 5
3/32 3.9 98 0.36 7 77005 5
7/64 4.1 104 0.36 8 77006 5
1/8 4.4 113 0.37 8 77007 5
9/64 4.8 121 0.37 8 77008 5
5/32 5.1 130 0.38 9 77009 5
3/16 5.3 134 0.44 10 77010 5
7/32 5.7 144 0.48 12 77011 2
1/4 6.5 164 0.49 12 77012 2
5/16 7.1 180 0.61 14 77013 2
3/8 7.8 199 0.84 18 77014 2
1.5 3.5 89 0.24 6 77050 5
2.0 3.9 100 0.32 8 77052 5
2.5 4.4 111 0.35 9 77054 5
3.0 4.9 125 0.37 9 77056 5
4.0 5.6 143 0.38 10 77060 5
5.0 6.4 161 0.43 11 77064 2
6 6.8 173 0.50 13 77068 2
8 7.7 194 0.61 15 77072 2
10 8.4 214 0.82 21 77076 2
PART# QTY LIST EA
Singles
EXTRA
LONG
Inch
EXTRA
LONG
Metric
TAGGED/BARCODED
Inch
Sets
Metric
77037 SDBLX13BXL 13 Extra Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
77099 SDBLX9MBXL 9 Extra Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
PART# MODEL# PCS LENGTH CONTENTS QTY LIST
77037
Stubby fi ts
where others
cannot
9
