Samsung Component Placer CP45FV Series Maintenance Reference
1.3.2. Other Tools Provided
Spanner
(7mm)
T wrench
Lubricant for nozzle
(Nozzle Spring)
Spray for removing
foreign matter fro
m
nozzle
Driver Monkey spanner
Spanner (46mm) Precision screw driver set
7mm Spanner: Material number J1700011
T: Material number J9099034A
Lubricant for nozzle: Material number J8001073A
Spray: Material number J8001072A
Driver: Material number J8001065A
Monkey spanner: Material number J8001066A
46mm Spanner: Material number J1700028
Precision screw driver set: Material number J1700015
1-6
Daily Inspection
Chapter 2. Daily Inspection
2-1
2.1. Nozzle
Inspection
Check the nozzle to see if an excessive wear occurs or if the tip of the nozzle has been
altered due to impact. In addition, check to see if any contamination, such as solder paste
is clogging the nozzle.
Solution
Clean the nozzle with cleaning liquid in case of contamination, or replace the nozzle if an
excessive wear was detect.
How to remove contaminant on the nozzle
Removing contaminant on the nozzle hole
Spray the recommended cleaning liquid on the nozzle hole by using a spray straw
After 1 minute, blow out the cleaning liquid from the tip of the nozzle by using
air pressure.
Blow out all the cleaning liquid from the nozzle hole.
If the contaminant is not removed by above method, repeat it once more.
If the contaminant still remains, contact the local agent.
Removing contaminant from the wings and tip of the nozzle
Samsung Component Placer CP45FV Series Maintenance Reference
Damp a piece of cloth with the recommended cleaning liquid by using a spray
straw.
Wipe the wings or tip of the nozzle with the dampened cloth.
Wipe off all cleaning liquid with a piece of clean cloth.
If the contaminant is not removed by above method, repeat it once more.
If the contaminant still remains, contact the local agent.
Recommended cleaning liquid: CHEMTECH Sticker Remover spray
Available at: Our company
Caution
Precautions
Precautions for handling written on the container
must be followed.
Do not spray toward a flame.
Keep away from heat, sparks, and open flame.
Do not keep it in the temperature of over 40 °C.
Do not use it in a closed space.
Do not dispose the container in the fire. Remove all
gas and dispose it.
Do not inhale the vapor and avoid contact with
skin, eyes, and clothes.
After use, turn the container upside down and
spray the remaining liquid.
Keep it away from children.
Do not swallow it.
Do not use it for purposes other than cleaning the
hole, wings, and tip of the nozzle.
Please refer to Material Safety Data Sheets for
details.
2.2. Feeder Base Cleaning
Inspection
Perform visual inspection to determine whether there are any chips or foreign matter on
the upper surface of the feeder base, which can cause pick-up error by distorting the
component pick-up point when setting the feeder.
Solution
Remove any chips or foreign matter from the upper surface of the feeder base using the
brush provided.
