Gantry
Page 19 / 21 24.11.2021
Pos. Item no. Description Part marking
76 00358054-01 SUPPORT Y TRAILING S25HM2 SPARE PART
78 00343998-01 SYNCHR. DISK Y ST 50 AT5/13-0
ACC.T.DRAW.
79 00095471-01 PLAIN WASHER A 3.2-140HV-ST
80 00341988-01 HEXAGON SOCKET HEAD CAP
SCREW M6*10
81 00845017-01 HEXAGON SOCKET HEAD CAP
SCREW
82 00300561-04 WRENCH
83 00095472-01 PLAIN WASHER A 4.3-140HV-ST
84 00308083-01 HEXAGON SOCKET HEAD CAP
SCREW
85 00337332-01 ABSORBER Y-AXIS S23 SPARE PART
86 00337334-01 SUPPORT S23
87 00316418-03 LEAF SPRING
88 00095470-01 WASHER
89 00305549-01 HEXAGON SOCKET HEAD CAP
SCREW
90 00337335-01 FRICTION BLOCK Y-AXIS S23
91 00318159-03 CLAMPING METAL
92 00095313-01 SLOTTED COUNTERSUNK HEAD
SCREW
93 00095311-01 DIN 965-M4 X 8-8.8,VERCU+NI
94 00095472-01 PLAIN WASHER A 4.3-140HV-ST
95 00095564-01 HEXAGON NUT
96 00337338-01 COMPRESSION SPRING 1.1*7.5*16
97 00845023-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 6-8.8
98 00337328-01 FRICTION BLOCK BRACKET Y-AXIS
S23/F5HM
SPARE PART
99 00304972-01 DEEP-GROOVE BALL BEARING
6*12*4 126-2Z
SPARE PART
100 00048325-01 LOCK WASHER
101 00317861-03 SPRING PLATE SPARE PART
102 00337329-01 FRICTION BLOCK Y-AXIS S23/F5HM SPARE PART
103 00337330-01 PRESSURE PLATE S23
104 00317858-02 CLAMPING PLATE
105 00095306-01 SLOTTED COUNTERSUNK HEAD
Gantry
Page 20 / 21 24.11.2021
Pos. Item no. Description Part marking
SCREW
106 00095471-01 PLAIN WASHER A 3.2-140HV-ST
107 00095563-01 HEXAGON NUT M 3 - ST
108 00317868-01 COMPRESSION SPRING 0,8*8,8*21,5 SPARE PART
00355911-01 SET OF ADJUSTING PLATES FOR
GANTRY
Spare Part
110 00095021-01 HEXAGON SOCKET HEAD CAP
SCREW
111 00334137-01 GUIDE TROLLEY S23 F-302939-11 SPARE PART
112 00304097S04 GUIDE PLATE SET COMPLETE Spare Part
114 00308279-01 DISTANCE BOLT M3X20 I/O HEX5,5
ST ZC
STANDARD PARTS
116 00319702-01 PCB PROTECTION
117 00324407-01 SPACER BOLT, TYPE B I/A-M3X7-ST STANDARD PARTS
118 00313426-01 DISTANCE BOLT M3*10 I/A 6KT5.5
BRASS
120 00366389-01 BUFFER Y-AXIS S27HM LEFT SIDE
121 00304966-01 ELASTOMER SPRING 8,5*16 (90
SHORE A)
SPARE PART
122 00337381-04 BUFFER Y-AXIS S23 RIGHT SIDE
123 00337382-03 STOP HOLDER RIGHT SIDE S23
124 00305650-01 SLEEVE SPARE PART
125 00095143-01 HEXAGON SOCKET HEAD CAP
SCREW
126 00301040-01 ELASTOMER SPRING 25*10,5*50
(90 SHORE A)
SPARE PART
127 00337383-02 END STOP EXTENSION S23
129 00321607-03 BELT GUIDE Y-AXIS SPARE PART
130 00845058-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 16-8.8, COPPER + NI-
PLATED
131 00362671-01 BRECOFLEX TOOTHED BELT Y-AXIS
S-27 HM
WEAR PART
132 00355912-02 STEEL MEASURING ROD S-27 HM Y-
AXIS
SPARE PART
136 00353807-02 CODING RAIL S27HM
138 00334154S02 Y-MOTOR (S23) Spare Part
139 00845058-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 16-8.8, COPPER + NI-
PLATED
Gantry
Page 21 / 21 24.11.2021
Pos. Item no. Description Part marking
140 00300970-02 AIR DISTRIBUTOR SPARE PART
141 00318551S03 SEVENFOLD TUBE PK-3, BLACK 4
METER
SPARE PART
142 00200485-04 FULL RELIEF FOR Y-CABLE HOLDER
143 00318601-03 COVER X-CABLE TRAIL.UNIT FOR
7-FOLD TUBE
SPARE PART
144 00304137-01 PIN FOR Y-CABLE TRAILING UNIT
HOLDER
145 00300628-03 DISTANCE LIGHT BARRIER
146 00316753S02 CABLE DUCT PLASTIC 80S SPARE PART
147 00303279-02 CABLE CLAMP
148 00321136-01 PULL RELIEF Y-CABLE HOLDER SPARE PART
149 00325198-03 X-CABLE CLAMP SPARE PART
151 00349457-05 SCANNER HEAD Y-AXIS, DIGITAL SPARE PART
152 00300601-05 PROXIMITY SWITCH: ENDPOSITION
Y-AXIS
SPARE PART
153 00300905-05 PROXIMITY SWITCH: LIMIT Y-AXIS SPARE PART
154 00321314-02 PCB-COVER SPARE PART
155 00845012-01 HEXAGON SOCKET HEAD CAP
SCREW M3 X 5-8.8, COPPER + NI-
PLATED
157 00354764-01 CONVERSION BOARD LARGE AXIS
S-27 HM
SPARE PART
158 00354432S02 GANTRY-HEAD DISTRIBUTOR
COMPL. F5HM ONLY
SPARE PART
00375273-01 CABLE ABRASION PROTECTION FOIL SPARE PART
00375276-01 LE ABRASION PROTECTION FOIL
SELF-ADHE
SPARE PART
