4OM-1505
1-59
5. List of Consumables and Servicing Parts : Chap.1
5. List of Consumables and Servicing Parts
5.1 List of Consumables
This component list is for the components that would be worn within one year.
When any of these components are to be purchased, contact Marketing Dept. of
HITACHI High-Technologies or our sales agent.
Product/Block
Name
Product
Name
Product
No.
Part No. Part Name
Standard and
Material
Q’ty
Recommended
# of Years
Remarks
Selected
Components
Squeegee
211H0454 SHEET
Urethane Rubber
6T×30W×530L
Hardness: 90°
2
Squeegee
211H0261 SHEET
Urethane Rubber
6T×30W×350L
Hardness: 90°
2
Cleaning
Paper
0900H0A0 MECH PARTS
(PAPER)
LFT-100-5
(Width 350×28m)
Diameter: φ95
1
Cleaning
Paper
0900H0A1 MECH PARTS LFT-100-5
(Width 530×28m)
Diameter: φ95
1
T4A12
0906-001
4OM-1505
1-60
5. List of Consumables and Servicing Parts : Chap.1
5.2 List of Servicing Parts
This component list is for the components for which maintenance is required in
several years, for your reference.
Note
For the maintenance procedure for the important maintenance components,
consult with our service personnel because high skill is required for such
maintenance.
T4A13
Product/Block
Name
Product
No.
Part No. Part Name Standard and Material Q’ty
Recommended
# of Years
Remarks
B
Table
Section
S004 23G10001 SENSOR,
EE-SX670 5 3
S005 23G10002 SENSOR,
EE-SX671 3 3
S201 23G10002 SENSOR,
EE-SX671 3 3
S330 4W205000 CORD 1GG4W20050000
-1-2-3
1 6
S402 23G10001 SENSOR,
EE-SX670 2 3
S801 23G00146 SENSOR,
PELEC
E3T-ST11 1 3
S808 23G10029 SENSOR,
EE-SX672 1 3
S812 223Q0663 PULLEY,
TIMING
#T0304-2401
(P26-2GT)
6 5
S813 223M0059 PULLEY,
FLAT
#T0304-2402 7 5
S814 223L0383 BELT,
TIMING
1GG223L003830-- 2 3
S851 23G10002 SENSOR,
EE-SX671 1 3
F
Stencil
Holder
Section
S014 23G10056 SENSOR,
EE-SX674 2 3
S106 23G10056 SENSOR,
EE-SX674 3 3
FA
Squeegee
Head
Section
S105 23G10029 SENSOR,
EE-SX672 1 3
FB
Stencil
Recognition
Section
S006 23G10056 SENSOR,
EE-SX674 6 3
0906-001
4OM-1505
1-61
5. List of Consumables and Servicing Parts : Chap.1
T4A14
Product/Block
Name
Product
No
Part No. Part Name Standard and Material Q’ty
Recommended
# of Years
Remarks
G
PEC
Recognition
S010 23G00111 SENSOR,
PELEC
#E3S-LS3RC4 1 3
S012 23G10056 SENSOR,
EE-SX674 3 3
S112 23G10001 SENSOR,
EE-SX670 1 3
S307 23G10056 SENSOR,
EE-SX674 2 3
S308 23G10029 SENSOR,
EE-SX672 1 3
H
Conveyor
Section
S018 23G10056 SENSOR,
EE-SX674 2 3
S029 223Q0663 PULLEY,
TIMING
#T0304-2401
(P26-2GT)
8 5
S030 223M0059 PULLEY,
FLAT
#T0304-2402 8 5
S102 23G00243 SENSOR,
PELEC
E3S-LS3NW 1 5
S107 23G00269 SENSOR,
PELEC
E3T-FD11 1 5
S202 23G00243 SENSOR,
PELEC
E3S-LS3NW 1 5
S204 23G00269 SENSOR,
PELEC
E3T-FD11 1 5
S301 223L0398 BELT,
TIMING
1GG223L003980-- 4 3
R
Cover
Section
S002 4M130044 MOTOR,DC CNDC24Z7Q 2 9
S132 222R0054 SPRING
(GUS)
30Q0 2 5
S133 222R0057 SPRING
(GUS)
30Q3 2 5
M
Cleaning
Section
S004 23G10029 SENSOR,
EE-SX672 1 3
S005 23G00146 SENSOR,
PELEC
E3T-ST11 1 3
BB
Control
Board
S103 4U240503 UNIT,
DRIVER
#RS1L03AA03501P01 1 6
S109 4U240502 UNIT,
DRIVER
#RS1L03AA03601P01 1 6
S201 4U200275
UNIT,POWER
ZWS10-12/JA 1 10
S202 4U200276
UNIT,POWER
ZWS10-24/JA 1 10
S216 4U200335
UNIT,POWER
HWS1800T-48 HFP 1 6
S401 4M130044 MOTOR,DC CNDC24Z7Q 2 9
C
Control Box
Section
S003 4U210135 UNIT,
DISPLAY
1GG4U21001350-- 1 7
