Features and Options: VectraElite Prehea t • Pr eheater accessibility is quick and easy from the front of the machine • The Iso Thermal conv ec tion preheat utilizes heat on intake technology . The heating uniformity is …

The VectraElite is

an advanced highly

engineered wave soldering

system that delivers

the required accuracy,

repeatability, and process

flexibility for demanding

production environments.

The VectraElite combines

proven core subsystem

technology and new

advanced performance

leading technologies

designed for lead-free

alloys.

VectraElite

Accuracy, Repeatability and Process Flexibility

The VectraElite provides the technologies necessary to achieve zero-defect

process at the lowest cost of ownership.

• The VectraElite wave soldering system was originally launched in 2005 and continue to

be the market leader in delivering the most advanced wave soldering technologies at the

lowest cost of ownership possible.

• Process control, process capability, and process exibility are all competitive advantages to

Electrovert wave soldering.

• All-in-one touchscreen PC with Windows 10 (64 bit) based operating system. The PC is

mounted on an articulating arm.

• Intuitive graphical user interface that makes set-up and operation easy.

• Data logging of all critical machine parameters and trending are standard in the machine

software.

• The ethernet based I/O system is common across all Electrovert wave, reow and cleaning

products (commonality of spare parts).

• The VectraElite is UL Certied and Listed for Factory Automation as standard.

• All Electrovert systems are made in the USA.

Features and Options:

VectraElite

Preheat

• Preheater accessibility is quick and easy

from the front of the machine

• The IsoThermal convection preheat

utilizes heat on intake technology. The

heating uniformity is very eective and

ecient across the entire heating area

Solder Module

• All Electrovert wave systems have a

lifetime warranty on the solder pot

casting (applies to original owner)

• For N soldering applications, the

available features include:

• N boundary soldering (inerts at the

waves)

• Short N tunnel (inerts the entire

solder module area and wave)

• Full N tunnel (inerts all preheat

sections, the entire solder module

and at the waves)

• Integrated fume extraction into

back hood

Accessibility

• Lift up hoods with gas shocks and

hinged swing-out panels provide

unobstructed access to the front of

the machine

• Integrated step across front of

machine provides exceptional

accessibility for process set-up

Full access to all modules

IsoThermal Convection

Preheat (ICP)

Optional Dual Head

ServoJet

Lead Free Applications

• All Electrovert waves are lead free

qualied and optimized as standard

Fluxer Types

• ServoSpray spray uxer (single head

or dual head)

• ServoJet jetted spray uxer (available

in single head, dual head, OA types

and with selective uxing features)

• ServoSonic ultrasonic type spray uxer

Rolled out Solder pot

Conveyor

• Single continuous nger type conveyor

through the entire length of machine

• No limitation on board length (min

and max)

• Robust conveyor design capable of

100 lbs (43.4 kg) evenly distributed

throughout the conveyor length

View from front with all doors and hoods open.

Wave Solder Nozzles

• Electrovert solder nozzles deliver

exceptional soldering performance

for demanding applications

• DwellMax Plus provides excellent

topside hole ll and throughput.

Ideal for high thermal mass boards.

• DwellFlex 4.0 provides process

exibility with an on-the-y

adjustable wave contact length.

At maximum oers the most contact

length in the industry for high

thermal mass circuit boards and at

minimum is ideal for low mass wave

circuit boards.

DwellFlex 4.0 Adjustable

Wave Contact Nozzle

DwellMax Plus

Process Knowledge and Support

At ITW EAE, we deliver world-class products, performance, and unparalleled service and support programs.

With the VectraElite comes the prociency of our Electrovert process experts that allows us to solve real-

world applications issues. Knowledge in Process for superior performance.

Feature VectraElite (VC-3)

Process

Alloy Type Lead Free (Qualied and Optimized) S

Process Width Maximum PCB Width

18” (457 mm)

20” (508 mm)

Physical

Characteristics

Machine Length Length of machine with rail guides (Load/Unload)

163.8” (4.16 m)

177.5” (4.5 m)

Conveyor

Maximum Load Weight 100 lb (45 kg)

Motorized Width O

Preheat

Preheat Type

IR Platen S/O

IsoThermal Forced Convection S/O

Fast Response IR O

Preheat Length

Bottom

S (Qty. 2) at 4’ (1.2 m)

(Qty. 3) at 6’ (1.8 m)

Top O

(Qty. 2) at 4’ (1.2 m)

Solder

Soldering Environment Environment

S Air

O N

Main Wave UltraFill Air

Dual/Adjustable Wave

Contact Length

Chip Wave O

DwellMax Plus O

DwellFlex 4.0 O

Nozzle Material

Melonite Coated, Stainless Steel S

Titanium O

N Soldering

UltraFill N (Boundary Type) O

Short Tunnel (Inerts entire solder pot area) O

Full Tunnel (Inerts entire solder pot and ALL preheat areas)

(Compatible with IR in #3 bottom position)

Wave

Wave Height

S 12.7 mm

O Up to 25 mm

ExactaWave (Automatic wave height control) O

Casting Lifetime Warranty on Solder Pot Casting S

HMP High Melting Point Capability (Special Warranty Applies) RFQ

Fluxer

Fluxer Types and

Options

ServoSpray S

ServoJet O

OA ServoJet O

ServoSonic O

Flux Spray Start/Delay (ServoSpray/ServoSonic) S

Selective Fluxing (includes ux spray start/delay)

OA Servojet

High speed Servojet

Dual Flux Tank / Single Flux Head

Dual Flux Head / Dual Flux Tank

Teon Coated Flux Tank

Operating System

Software and Controls

Windows 10 - 64 bit S

Ethernet Based I/O S

UL UL Listed for Factory Automation Equipment S

CE Certication

Country of Origin Made in USA Factory based R&D and Software Engineering, and Applications Support Camdenton, MO USA

www.itweae.com

ITW EAE is a division of Illinois Tool Works, Inc. It is a consolidation of all of its Electronic Assembly

Equipment and Thermal Processing Technology. The group includes world-class products from MPM,

Camalot, Electrovert, Vitronics Soltec and Despatch.

Cleaning & Soldering Solutions

O = Optional; S = Standard; RFQ = Request Factory Quote

VECTRAELITE SPECIFICATIONS
