MODEL TCM-3100J-2 0108-001 233 Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 11 - 1 9 1 630 059 0104 BR AC KE T 1 659H--03B-042 2 - 1 411 0 51 17 08 SCR TRS 4X6 1 M4X6 TRS 2 -2 41 1 1 14 7807 SC R P AN+ SW +W 4X10 1 3…

100%1 / 268
MODEL TCM-3100J-2
0108-001
232
㔚᳇೙ᓮㇱ ELECTRICAL SECTION
Fig.11-19 ࠦࡦࡌࠕ㚟േ࿁〝㧾 Conveyor Driver Circuit R
13
12
11
13
12
11
25-1
26-1
26
25
29
28
27
13
13
12
12
11
11
10
1
21
24
23
22
42
41
92
51
92
92
91
91
74
74
73
73
72
71
See Fig.8-1
Key No.2
82
82
83
83
81
81
24
23
22
21
21
101
100
103
102
8-1
8
.
2
9
2-2
9
2-1
53
59
59
59
59
52
52-1
55
55
58
58-1
.
52-2
98
99
97
96-1
B
98
99
97
96-2
96-2
B
4
5
3
6
.
A
A
Fig.11-19
TCM-3100J-2
MODEL TCM-3100J-2
0108-001
233
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-19
1 630 059 0104 BRACKET 1 659H--03B-042
2 -1 411 051 1708 SCR TRS 4X6 1 M4X6 TRS
2 -2 411 114 7807 SCR PAN+SW+W 4X10 1
3 630 049 3801 TERMINAL 11 659FD-03D-008
4 630 049 3702 ACCESSORY,WIRING 2 659FD-03D-006
5 630 049 3733 ACCESSORY,WIRING 1 659FD-03D-005
8 630 049 1173 FUSE HOLDER 2 659FD-03D-012
8 -1 423 022 8203 FUSE 250V 3.15A 2 F118, F126 659FD-03D-013
9 630 057 4326 TERMINAL 2 659FD-03D-014
10 630 059 0128 PLATE 1 659H--03B-041
11 411 141 4008 WASHER V 4X9X0.8 4 FW4
12 411 141 2905 WASHER SPR 4 4 SW4
13 630 000 7619 BOLT,HEX-SCT 4 M4X8
21 630 049 1210 RELAY 4 SSR3, SSR100, SSR101, SSR102
659FD-03D-001
22 411 119 2104 WASHER V 4X9X0.8 8 FW4 F
23 411 008 1706 WASHER SPR 4 8 SW4 F
24 411 042 3001 SCR PAN 4X10 8 M4X10 PAN
27 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
28 411 008 1706 WASHER SPR 4 4 SW4 F
29 411 043 5004 SCR PAN 4X8 4 M4X8 PAN
41 630 058 8224 COVER 1 659H--03B-024
42 411 051 1708 SCR TRS 4X6 2 M4X6 TRS
51 630 062 2829 BOX 1 659FB-03V-040
52 -1 411 051 1708 SCR TRS 4X6 1 M4X6 TRS
52 -2 411 114 7807 SCR PAN+SW+W 4X10 1
53 630 049 3801 TERMINAL 1 659FD-03D-008
55 630 049 3733 ACCESSORY,WIRING 1 659FD-03D-005
58 630 049 1173 FUSE HOLDER 1 659FD-03D-012
58 -1 423 022 8203 FUSE 250V 3.15A 1 F131 659FD-03D-013
59 630 057 4326 TERMINAL 3 659FD-03D-014
71 630 049 1210 RELAY 2 SSR8, SSR9 659FD-03D-001
72 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
73 411 008 1706 WASHER SPR 4 4 SW4 F
74 411 043 5004 SCR PAN 4X8 4 M4X8 PAN
81 411 141 4008 WASHER V 4X9X0.8 2 FW4
82 411 141 2905 WASHER SPR 4 2 SW4
83 630 000 7626 BOLT,HEX-SCT 2 M4X10
91 630 062 2812 COVER 1 659FB-03V-041
92 411 051 1708 SCR TRS 4X6 4 M4X6 TRS
97 411 141 4008 WASHER V 4X9X0.8 4 FW4
98 411 141 2905 WASHER SPR 4 4 SW4
99 630 000 7619 BOLT,HEX-SCT 4 M4X8
100 411 087 0508 WASHER IN TW 4 1
101 411 114 7807 SCR PAN+SW+W 4X10 1
102 411 087 1109 WASHER IN TW 5 1
103 411 036 8609 SCR PAN+SW+W 5X12 1
