35(9(17,9( 0$,17(1$ 1&( 6,;0217+ /<0$,17( 1$1&( Chapter Issue 4 May 03 Technical Reference Manual 29.13 SIX MONTHL Y MAINTENANCE (or 260,000 Cycl es, whichever is soonest) . W ARNIN G HARMFUL SUBST ANCE S. …
35(9(17,9(0$,17(1$1&(
0217+/<0$,17(1$1&(
29.12 Technical Reference Manual Chapter Issue 4 May 03
Rising Table Figure 29-11 refers.
Chase Figure 29-8 refers.
Screen Actuators Figure 29-5 refers.
No. Task Tools Completed Comments
1 Clean the table linear bearings to remove solder
paste or debris.
IPA Impregnated
Wipes
2 Check operation of the rising table brake.
3 Cycle the rising table ensuring smooth running.
No. Task Tools Completed Comments
1 Clean the Omni track plates to remove any
solder paste or debris.
IPA Impregnated
Wipes
2 Lightly lubricate the Omni track bearings and
plates.
Light Grease
No. Task Tools Completed Comments
1 Clean the roller bearings and striker plates to
remove any solder paste or debris.
IPA Impregnated
Wipes
2 Lubricate the roller bearings. Light Grease
3 Lubricate the striker plates. Light Oil
4 Check the condition of the roller bearings
ensure the bearings are free to rotate.
Total estimated time required for monthly tasks 75 mins
35(9(17,9(0$,17(1$1&(
6,;0217+/<0$,17(1$1&(
Chapter Issue 4 May 03 Technical Reference Manual 29.13
SIX MONTHLY MAINTENANCE
(or 260,000 Cycles, whichever is soonest).
WARNING
HARMFUL SUBSTANCES. CLEANING WIPES AND CLEANING SOLUTIONS MAY
CONTAIN SUBSTANCES HAZARDOUS TO HEALTH. OBSERVE ALL
MANUFACTURERS’ HEALTH AND SAFETY GUIDELINES. ALWAYS WEAR
APPROVED PROTECTIVE CLOTHING WHEN CLEANING THE MACHINE.
Preparation The machine must be isolated from electrical power and air pressure.
Machine PC Enclosure
Machine Controller Enclosure
M24 Power Supply Unit
Squeegee Assembly
X and Y Camera
Axes
Figure 29-9 refers.
No. Task Tools Completed Comments
1 Clean the fan assembly and guard.
No. Task Tools Completed Comments
1 Clean the three enclosure fan assemblies and
guards. Gain access and clean the three base
frame fan assemblies and guards.
Medium Flat
Bladed Screw-
driver
No. Task Tools Completed Comments
1 Clean the fan assembly and guard. 3mm Allen Key
No. Task Tools Completed Comments
1 Clean the housing to remove any solder paste
or debris.
IPA Impregnated
Wipes
2 Check the condition/tension of the drive belts.
NOTE
See Squeegee Chapter for procedure
No. Task Tools Completed Comments
1 Lubricate the camera X linear bearing.
NOTE
Using a grease gun pump the bearing with the
recommended grease until it starts to leak from
the bearing. Wipe away any excess grease.
Grease Gun
THK AFB Grease
35(9(17,9(0$,17(1$1&(
6,;0217+/<0$,17(1$1&(
29.14 Technical Reference Manual Chapter Issue 4 May 03
ProFlow Assembly
Vacuum Filtration Unit
Figure 29 - 14 refers.
NOTE
Available replacement parts are detailed in the table below.
No. Task Tools Completed Comments
1 Clean the housing to remove any solder paste
or debris.
IPA Impregnated
Wipes
2 Check the condition/tension of the drive belts.
NOTE
See ProFlow Chapter for procedure.
No. Task Tools Completed Comments
1 Inspect pre-filter filter for contamination.
Remove any loose debris.
NOTE
Replace filter if found to be heavily contami-
nated.
2 If pre-filter is found to be heavily contaminated,
replace carbon filter unit.
NOTE
The life of the filters are dependant upon unit
usage. If the vacuum unit is subject to sus-
tained frequent use the filters may require
changing sooner.
Description Items DEK Part Number
Consumable Kit - Both Voltages Pre-Filter (163551) - 1 unit
Carbon Filter (163552) - 1 unit
173102
Fuses 230V - 5 Amp (pack of ten) 121114
110V - 10 Amp (pack of ten) 160237
Hose Grey Hose (100mm x 38mm dia) 163555
Black Hose (200mm x 38mm dia) 163556
Solid State Relay - 50A (both voltage options) 163553
Total estimated time required for six monthly tasks 30.0 mins
