101 1-001 16 13 1 1 15 14 16 7 6 3 4 18 5 17 12 72mm TF Fig. TD DS-72002 Fig. TD-1 継ぎ目検出ユニット Joint Detection Unit Fig. TD 継ぎ目検出ユニット DS-72002 Joint Detection Unit DS-72002
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
523 221DA051 MACHINE SCREW 6 1092600700-023
532 221DA007 MACHINE SCREW 2 1092600700-032
580 4W202800 CORD 1 1092600700-130
581 4W202883 CORD 1 1092600700-131
582 4W202923 CORD 1 1092600700-132
584 4W300034 WIRE 1 1092600700-134
586 4U240497 UNIT,DRIVER 1 1092600700-136
GT-72002
Fig. T
0912-002
Fig. T-6
72mm TF
Fig. T
GT-72002
1011-001
16
13
11
15
14
16
7
6
3
4
18
5
17
12
72mm TF
Fig. TD
DS-72002
Fig. TD-1
継ぎ目検出ユニット
Joint Detection Unit
Fig. TD
継ぎ目検出ユニット
DS-72002
Joint Detection Unit DS-72002
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1011-001
72mm TF
Fig. TD
DS-72002
3 0926200R PLATE INDEX 1 109260070A-003
4 0926200S PLATE INDEX 1 109260070A-004
5 221AA105 BOLT_HEX-SCT 2 109260070A-005
6 211DA550 PLATE 1 109260070A-006
7 221DA115 MACHINE SCREW 2 109260070A-007
11 210B4392 FRAME 1 2092600F00-001
12 0926J005 ASSY COVER 1 2092600F00-002
13 211A9111 COVER(D) 1 2092600F00-003
14 23G10090 SENSOR,PHOTO 1 2092600F00-004
15 221DA065 MACHINE SCREW 2 2092600F00-005
16 221DA103 MACHINE SCREW 4 2092600F00-006
17 221DA056 MACHINE SCREW 2 2092600F00-007
18 0926J00B GUIDE 1 2092600F00-008
DS-72002
Fig. TD
Fig. TD-1
