https://www.phoenixcontact.com/sg/products/3210567
05/27/2020Page25/31
Double-level terminal block-PTTB 2,5-3210567
Accessories
Zack Marker strip, flat-ZBF 5,LGS:FORTL.ZAHLEN-0808671
Zack Marker strip, flat, Strip, white, labeled, printed horizontally: consecutive numbers 1 ... 10, 11 ... 20, etc. up to
491 ... 500, mounting type: snap into flat marker groove, for terminal block width: 5 mm, lettering field size: 5.15 x
5.15 mm, Number of individual labels: 10
Zack Marker strip, flat-ZBF 5,QR:FORTL.ZAHLEN-0808697
Zack Marker strip, flat, Strip, white, labeled, Printed vertically: consecutive numbers 1 ... 10, 11 ... 20, etc. up to 91 ...
100, mounting type: snap into flat marker groove, for terminal block width: 5 mm, lettering field size: 5.15 x 5.15 mm,
Number of individual labels: 10
Zack Marker strip, flat-ZBF 5,LGS:GERADE ZAHLEN-0810821
Zack Marker strip, flat, Strip, white, labeled, printed horizontally: consecutive numbers 2 ... 20, 22 ... 40, etc. up to
82 ... 100, mounting type: snap into flat marker groove, for terminal block width: 5 mm, lettering field size: 5.15 x 5.15
mm, Number of individual labels: 10
Zack Marker strip, flat-ZBF 5,LGS:UNGERADE ZAHLEN-0810863
Zack Marker strip, flat, Strip, white, labeled, printed horizontally: Odd numbers 1 - 19, 21 - 39, etc. up to 81 - 99,
mounting type: snap into flat marker groove, for terminal block width: 5 mm, lettering field size: 5.15 x 5.15 mm,
Number of individual labels: 10
Marker for terminal blocks-UC-TMF 5 CUS-0824638
Marker for terminal blocks, can be ordered: by sheet, white, labeled according to customer specifications, mounting
type: snap into flat marker groove, for terminal block width: 5.2 mm, lettering field size: 4.6 x 5.1 mm, Number of
individual labels: 96
https://www.phoenixcontact.com/sg/products/3210567
05/27/2020Page26/31
Double-level terminal block-PTTB 2,5-3210567
Accessories
Marker for terminal blocks-UCT-TMF 5 CUS-0829658
Marker for terminal blocks, can be ordered: by sheet, white, labeled according to customer specifications, mounting
type: snap into flat marker groove, for terminal block width: 5.2 mm, lettering field size: 4.4 x 4.7 mm, Number of
individual labels: 72
Marker carriers
Marker carriers-STP 5-2-0800967
Double marker carrier, snaps onto the double-level spring-cage terminal block STTB 2,5, STTB 4, PTTB 2,5, PTTB 4
can be marked with UC-TM 5, ZB 5 or UC-TMF 5, ZBF 5
Marker carriers-STP 5-2/S-0800970
Double marker carrier, snaps onto the double-level spring-cage terminal block ZFKK 1,5, with MSTBV or ICV pick-off
Partition plate
Partition plate-ATP-STTB 4-3030747
Partition plate, length: 88.7 mm, width: 2 mm, height: 53 mm, color: gray
Spacer plate-DP PS-5-3036725
Spacer plate, length: 22.4 mm, width: 5.2 mm, height: 29 mm, number of positions: 1, color: red
Planning and marking software
https://www.phoenixcontact.com/sg/products/3210567
05/27/2020Page27/31
Double-level terminal block-PTTB 2,5-3210567
Accessories
Software-CLIP-PROJECT ADVANCED-5146040
Multilingual software for convenient configuration of Phoenix Contact products on standard DIN rails.
Software-CLIP-PROJECT PROFESSIONAL-5146053
Multilingual software for terminal strip configuration. A marking module enables the professional marking of markers
and labels for identifying terminal blocks, conductors and cables, and devices.
Screwdriver tools
Screwdriver-SZF 1-0,6X3,5-1204517
Actuation tool, for ST terminal blocks, also suitable for use as a bladed screwdriver, size: 0.6 x 3.5 x 100 mm, 2-
component grip, with non-slip grip
Actuation tool-ST-BW-1207608
Actuation tool, for all 2.5 mm² - 4.0 mm² spring-cages
Terminal marking
Zack Marker strip, flat-ZBF 5:UNBEDRUCKT-0808642
Zack Marker strip, flat, Strip, white, unlabeled, can be labeled with: PLOTMARK, CMS-P1-PLOTTER, mounting type:
snap into flat marker groove, for terminal block width: 5 mm, lettering field size: 5.1 x 5.2 mm, Number of individual
labels: 10
