Boar d Ass’y 12-1 第 12 章 . Board Ass’y 12.1. Board Ass’y 所需材料
Samsung Component Placer SM411 Service Manual
11-8
Button
执行内容 执行内容
Restore
HDD
在新HDD进行驱动器划分设置及O/S设
置。
HDD中所有DATA被删
除。
Restore OS
在已设置O/S的HDD仅在C: 驱动器设置
O/S。
C: 驱动器的所有DATA被
删除。
Cancel
取消恢复。
请选择必要执行内容的按钮。
5~6分钟按照用户的设置Recovery CD的程序设置驱动器划分及O/S。
Board Ass’y
12-1
第 12 章. Board Ass’y
12.1. Board Ass’y所需材料
Samsung Component Placer SM411 Service Manual
12-2
NO. PART NO. PART NAME Q’TY
TYPE REMARK
1
J4809054A VME BACKPLANE 1
DSOVME-
12J1(REV.C)
2 J48011002A
SBC 1
HICORE-I9451VLG
3
J4809054A VME BACKPLANE 1
DSOVME-
12J1(REV.C)
4
J91741013A SM330_CAN_MASTER_BOARD 1 VER2.0
5
J9060063E CAN CONVEYOR BOARD ASSY 1
CAN CONVEYOR
(REV1.4)
6
J91741037A SAMC-62 1 G420-U01(STW)
7 J9060413A SM321 VISION I/F BOARD
1
J9060413A
8
J91741012A SM330_TWIN_SERVO_BOARD 1
VER1.0
9
J91741014A X7043_SEDES_BOARD 1
VER1.0
10
J91741015A X7043_STEP_CONTROL_BOARD 1
VER1.0
11
J9060417A FR OPERATE BOARD 1 J9060417A
OPTION
12 J9060408A
SM321 HEAD ILL BOARD 1
J9060408A
13
J91741016A SM330_VME_IO_BOARD 1 VER1.0
14
J9060193B PCI IO BOARD 1 VER 2.0
15
J9060418A MVME 3100 1 MVME 3100
16 J9060409A
SM321 HEAD I/O BOARD 1
J9060409A
17 J9060412A SM321 VACUUM SENSOR BOARD
1
J9060412A
18 J9060338A FEEDER IO BOARD 2 Rev 1.1 NON DOCKING
19
J9060339A FEEDER INPUT EXTENSION BOARD 2 Rev 1.0
20
J91741026A SM330_AXIS_SENSOR_BOARD 1 VER1.0
21
J9060346A CONV SUB I/F BOARD 1 Rev 1.0
22 J91741025A MEGA_CAMERA_IO_BOARDD
1
VER1.0
23 J9060347B
FEEDER BASE LEFT BOARD, NON DOCKING
2 REV 2.1
24 J9060348B
FEEDER BASE RIGHT BOARD, NON DOCKING
2 Rev 2.1
25 J91741023A CONVEYOR PWR BORAD 1 VER1.0
12.2. Control Rack Ass’y
12.2.1. 必要工具
十字 十字形(+)螺丝刀, 一字 一字形(-)螺丝刀
T Wrench or Hex Wrench
12.2.2. PC 部 Board Ass’y
Single Board Computer (SBC)
PCI I/O Board
Nexteye Board
12.2.2.1. PC 部 board ass’y 替换次序
1. 正常关闭PC后关闭设备前面的Main Switch。
