82 Mechanical Drawings 182162 Issue 1 Pneumatic V alve Layout GA A B C D REMOVE ALL BURRS & SHARP EDGES 45 6 1 2 3 45 6 1 2 3 A B C E E PROJECTION D DRAWN APPROVED DA TE C COPYRIGHT DO NOT SCALE SCALE TITLE DRAWING N…
Mechanical Drawings 81
182161 Issue 1 Covers Viking
F
E
D
C
B
A
654321
E
F
987
123456789
PROJECTION
D
C
B
A
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2002
BOM NUMBER
ITEM PART NO. DESCRIPTION QTY.
1
156932 WINDOW, AS 2
2
163160 FRONT LOWER PANEL ASSY 1
3
163162 REAR LOWER PANEL ASSY 1
4
182104 REAR TOP COVER ASSY 1
5
182106 SIDE LOWER REAR RIGHT 1
6
182108 SIDE LOWER FRONT RIGHT 1
7
182110 SIDE LOWER REAR LEFT 1
8
182114 SIDE LOWER FRONT LEFT 1
9
182115 FRONT TOP COVER ASSY 1
LATEST
ISSUE
No. DATE DCR INITIAL
01 17-Sep-02 +++ TH
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
3:20
INDUMO
COVERS VIKING
17-Sep-02
182161
182103
SH 1
OF 1
A
1
FRONT
REAR
2
5
6
9
1
3
4
7
8
82 Mechanical Drawings
182162 Issue 1 Pneumatic Valve Layout GA
A
B
C
D
REMOVE ALL BURRS & SHARP EDGES
456
1
2
3
456
1
2
3
A
B
C
E
E
PROJECTION
D
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2002
BOM NUMBER
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:5
THONNOR
PNEUMATIC VALVE LAYOUT GA
19-Sept-02
182162
163447
SH 1
OF 1
A
2
ITEM PART NO. DESCRIPTION QTY.
1
111316 BULKHEAD ( DIA 8mm x 1/4 BSP) 1
2
163449 8 STATION MANIFOLD ASSEMBLY SMC ELA BOM 1
3
165387 FILTER / REGULATOR /PRESSURE SWITCH GA 1
4
165442 BRACKET, FILTER / REGULATOR MOUN 1
5
165443 BRACKET, BULKHEAD FITTING MOUNT 1
6
G4266 TUBE - 8MM DIA (CUT TO LENGTH AS REQUIRED) 1
LATEST
ISSUE
No. DATE DCR INITIAL
01 19-Sept-02 +++ TH
P TRAY; 163451
2
4
6
3
1
5
SCALE 1:1
Mechanical Drawings 83
182163S1 Issue 1 GA Footprint Viking
54321
A
B
CC
B
A
12345
67
8
910
11 12
13
6
7
8
9
10 11
12
13
D
E
F
G
H
I
D
E
F
G
H
I
PROJECTION
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2002
BOM NUMBER
1609
85
1149
1314
320
1433
1548
61
1490
1284
DIMENSION C
1302
DIMENSION D
1452
DIMENSION B
1065
NOMINAL
145
DIMENSION F
1093
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
3:20
THONNOR
GA FOOTPRINT VIKING
23-Sep-02
182163
182055
SH 1
OF 2
A
0
LATEST
ISSUE
No. DATE DCR INITIAL
01 23-Sep-02 +++ TH
ALL DIMENSIONS SHOWN WITH MAXIMUM BOARD TRANSFER HEIGHT OF 980MM (DIMENSION A -SHEET 2)
DIMENSION B; SCREEN LOAD HEIGHT= 1065 MAX/ 905 MIN
DIMENSION C; MONITOR EYE HEIGHT= 1302 MAX/ 1142 MIN
DIMENSION D; MONITOR TOP HEIGHT= 1452 MAX/ 1292 MIN
DIMENSION E; FRONT OF MACHINE TO FRONT OF BOARD= 508 (SHEET 2)
DIMENSION F; kEYBOARD HEIGHT= 1093 MAX/ 933 MIN.
FRONT VIEW
RIGHT
LEFT
REAR
FRONT
TOP
VIEW
EXTREMITY OF MONITOR TRAY
FOLLOWS THE ARC OF MONITOR ARM.
R385
ARC OF MONITOR ARM
R 276
VIEW FROM RIGHT HAND SIDE
FRONT
REAR
