6 WF3 JTF-ML2 Maintenance Clean Conveyor (JTF-ML2) 5 min 1 / 1 C A U T I O N ! R e f e r t o s a f e t y i n s t r u c t i o n s i n u s e r m a n u a l b e f o r e c o m m e n c i n g M a i n t e n a n c e Machine Sta…
www.asm-smt.com
Safety Instructions for Work on the Cutting Device
WARNING!
Risk of injury when working near the cutter.
When working in the area of the tape cutter, move the component trolley
out of the machine and disconnect the machine from the mains supply and
the compressed air supply.
Wait until the operating pressure has dropped to 0 MPa.
Always secure the machine against unauthorized reactivation.
Do not reach into the tape cutter.
.
Safety Instructions on Hazardous Materials
CAUTION!
Observe the safety data sheets
Observe the applicable safety data sheet, when handling hazardous materials
(e. g. Loctite 241, ethanol).
.
Preparatory Work...
Purpose and Scope
Before performing any preventive maintenance work, conversion work or service
work, a procedure of locking and tagging must be followed and warning signs
must be attached if not stated otherwise. If it is not necessary to switch off the
machine, it is explicitly mentioned.
The procedure, when followed correctly, eliminates the possibility of an employee
being injured.
NOTICE!
Additional safety measures
These procedures represent the minimum lock/tag out requirements for the
machine during preventive maintenance work and service work. Any addi-
tional safeguards needed to complete work safely can be specified by facilit-
ies supervision, the safety officer, the safety committee and the health de-
partment.
.
Description
Whenever it becomes necessary to isolate, control and release energy, the follow-
ing procedure is to be followed.
u Notify affected employees.
u Switch off the machine and all additional devices. Carry out all normal stop-
ping procedures:
ð Press the STOP button.
ð Shut down the station computer.
ð Switch the machine off at the main switch.
u Isolate the machine from all its energy sources:
ð Shut off the compressed air supply.
ð Shut off the main power supply.
u Lock out the machine.
ð Attach a lock wherever possible (e.g. to the main power switch or the mo-
tor contactor).
6 WF3 JTF-ML2 Maintenance Clean Conveyor (JTF-ML2) 5 min 1 / 1
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Conveyor Empty
NOTICE! ESD guidelines are to be followed Tool:
T67
Wear Part: Consumables:
C3
www.asm-smt.com
1 For safety, use ESD wrist strap to pick up
components that are on the conveyor.
2 Check conveyor belt for contamination
and damage.
3 Clean all debris from belt.
4 Clean the debris stuck on the single disk
flexible coupling.
www.asm-smt.com
Equipment required for Workflow 3 Maintenance JTF-ML2
Tools
T31 00376492-xx Hexagon L-wrench set 1.5-10
T34 00378523-xx Craft brush
T67 00320279-xx ESD wrist strap
T69 00378526-xx Electronic screw driver
Wear parts
Consumables
C3 03082092-xx Lint free clothes
C49 03121952-xx Lubrication grease BEM 34-132. 400g cart.
