ASSEMBLY
16
ASSEMBLY
ASSEMBLY
CORE COMPETENCE
A range of process assembly solutions offered by IPTE includes
Automatic test
Automating production improves quality. Automating nal tests
makes quality control independent of the human factor and
guarantees zero defect. Traceability is a major asset in your quality
assurance system. For this reason, the pallet’s RF memory tag
stores not only the origin of parts and the production parameters,
but also the individual results of any measurement carried out. The
resulting comprehensive traceability record is then downloaded to a
database.
Packaging
The nal stage of many production lines is storage of products in
a variety of containers (such as magazines, trays, boxes). Some
products are even stored in individual boxes which in turn are
stacked on a pallet. Each individual box receives an identication
label for traceability. Trays can be combined in tray stacks.
Automated Guided Vehicles (AGV) transfer the packed products to
the warehouse for processing.
Part feeding techniques
Automatic part feeding is a basic component of assembly machines.
Efciency of a system and its protability, directly depends upon
the performance of the feeders. Our feeders are designed to permit
efcient feeding and placement.
1
2
3
4
5
FINAL TEST
Pick and place
High-speed pick and place robots take your product from one
location to another with pinpoint accuracy. Human pick and place
applications require repetitive motion over a long period, whereas
robots can increase efciency and reduce production costs and
ergonomic issues.
17
ASSEMBLY
Pressing
IPTE standard modules are equipped with a standardized four
columns and platform mounted structure together with a lower
anvil to support pallets during pressing operations. In this way, it
is easy to integrate pressing into your production line.
Robotics
To maximize links with external machines and especially with
automatic testers, IPTE has implemented Hi-Speed linear robots.
Standardized electronic and mechanical interfaces support robots
from the industry’s major brands. The new generation of Cobots
provide a new way of thinking for your application, permitting a
Cobot to work closely with operators.
Screw insertion
Tightening equipment is provided with travel, torque and angle
control devices which monitor the screw process. Additionally,
sensors control the screw height after the operation is completed to
ensure good results.
Turntables
IPTE’s turntables offer a signicantly larger central opening
for operator or robot feeding yet maintain the same external
dimensions to simplify system design. Using a suitable control
system further reduces the cycle time. Rotary tables can be
pneumatic or servo based. The number of indexes is optimized for
the number of parallel processes.
Welding
Welding, whether ultrasonic, laser or resistance, is a typical
assembly operation. Integrating robotics means it can be adapted
for a faster and more accurate process.
