13 8. Vision Head Section 8-1. Vision Head 9 13 13 5 15 15 15 16 8 10 12 2 17 1 19 16 16 4 13 4 1 1 18 15 15 16 16 7 3 6 9 13 13 5 15 15 15 16 8 10 12 2 17 1 19 16 16 4 13 4 1 1 18 15 15 16 16 7 3 6
12
7. Operation Box Section (Option)
7-1. Operation Box (Option)
3
4
5
6
7
1
2
8
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M5602-00 UY CASE ADD 1
2 LE1-M5603-00 LABEL 1
3 LE1-M66JT-10 HNS.OK.SW.ASSY CE 1
4 LE1-M66JU-10 HNS.NG.SW.ASSY CE 1
5 LE1-M66JV-10 HNS.EXE.SW.ASSY CE 1
6 LE1-M66JW-10 HNS.STP.SW.ASSY CE 1
7 LE1-M66NE-00 HNS.X312-X313 1
8 LE1-M66NA-01 HNS.X201-X312 1 1.5m
13
8. Vision Head Section
8-1. Vision Head
9
13
13
5
15
15
15
16
8
10
12
2
17
1
19
16
16
4
13
4
11
18
15
15
16
16
7
3
6
9
13
13
5
15
15
15
16
8
10
12
2
17
1
19
16
16
4
13
4
11
18
15
15
16
16
7
3
6
14
8. Vision Head Section
8-1. Vision Head
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M7211-03 BRACKET,CAMERA(1) 1
2 LE1-M7212-01 BRACKET,LENS 1
3 LE1-M7213-03 HOLDER,CAMERA(1) 1
4 LE1-M7215-01 HOLDER,CAMERA(3) 2
5 LE1-M7216-04 BRKT,USB 1
6 LE1-M7217-02 STAY 1
7 LE1-M7218-02 STAY 1
8 LE1-M7311-00 BRACKET,LITHING(L) 1
9 LE1-M72H1-01 COLOR CAM200U 1
10 LC3-M76A2-20 LENS 1
11 LG7-M71GY-30 BOLT HEX.SOCKET HEAD 4
12 LE1-M7300-50 LIGHTING UNIT SEC. 1
13 91314-03008 BOLT HEX.SOCKET HEAD 6 M3X8
14 91314-04008 BOLT HEX.SOCKET HEAD 2 M4X8
15 91314-04012 BOLT HEX.SOCKET HEAD 24 M4X12
16 91317-05018 BOLT HEX.SOCKET HEAD 6 M5X18
17 91317-05025 BOLT HEX.SOCKET HEAD 1 M5X25
18 92A08-03308 SET SCREW 2 M3X8
19 92A08-04310 SET SCREW 2 M4X10
