– 1 14 – E2 181 1-006 5 Cutter 418 419 415 414 413 423 408 410 412 409 405 406 404 429 401 403 406 425 427 402 430 424 428 422 421 420 404 417 416 407 4 11 443 441 442 438 438 439 439 440 437 437 434 433 432 431 437 435 …
– 113 –
CUTTER SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
301 KYB-M3T2G-00 211DE955 PLATE 1
302 KYB-M3T2K-00 211FE952 BRACKET 1
303 KYB-M3T14-00 211G6341 BLOCK 2
304 KYB-M3T36-00 222P0203 SPRING,TORSION 2
305 KYB-M3T2Y-00 216D0443 PIN,HINGE 4
306 KYB-M3T30-00 216D0444 PIN,HINGE 2
307 KYB-M3T31-00 216D0608 PIN,HINGE 4
308 KYB-M3T21-00 0920H15Q LEVER 1
309 KYB-M3T22-00 0920H15R LEVER 1
310 KYB-M3T32-00 216S2820 LEVER 1
311 KYB-M3T33-00 216S2821 LEVER 1
312 KYB-M3T17-00 0920715E ASSY_CLAMPER_Y 1
312-01 KYB-M3T0M-00 0920H15G LEVER 1
312-02 KYB-M3T1J-00 0920H12X CLAMP_GUM 1
313 KYB-M3T16-00 09207152 ASSY_CLAMPER_K 1
313-01 KYB-M3T01-00 0920H150 LEVER 1
313-02 KYB-M3T1R-00 0920H153 CLAMP_GUM 1
314 KYB-M3T3S-00 222A0150 BUSH,BEARING 4
315 KYB-M3T3R-00 222A0149 BUSH,BEARING 4
316 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 4 M3L6
317 92902-03100 221HA003 WASHER,SPRING 8 SW3
318 92902-03200 221HA103 WASHER,PLAIN 8 FW3
319 91312-03004 221AA004 BOLT,HEX.SOCKET HEAD 4 M3L4
– 115 –
CUTTER SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
401 KYB-M3T00-00 0920H147 BASE 1
402 KYB-M3T1L-00 0920H13U LEVER_STOPPER 1
403 KYB-M3T0J-00 0920H12H PIN 1
404 KYB-M3T1A-00 0920H127 DISK 2
405 KYB-M3T1P-00 0920H14Z SHAFT 1
406 KYB-M3T0N-00 0920H15H GUIDE 1
407 KYB-M3T3V-00 222D0412 BEARING,RADIAL 2
408 KYB-M3T1B-00 0920H12A HOLDER 1
409 KYB-M3T1C-00 0920H12D COLLAR 1
410 KYB-M3T1S-00 0920H156 HOLDER 1
411 KYB-M3T1U-00 0920H159 SEAL 1
412 KYB-M3T1V-00 0920H15A SEAL_COVER 1
413 KYB-M3T2N-00 213A1411 SHAFT 1
414 KYB-M3T2T-00 213A1610 SHAFT 1
415 KYB-M3T0K-00 0920H12T GUIDE 1
416 90933-01J800 222D0376 BEARING,RADIAL 2
417 KYB-M3T34-00 222E0017 BEARING,THRUST 1
418 KYB-M3T2X-00 216B1514 HOLDER 1
419 KYB-M3T35-00 222M1378 SPRING,COMP 1
420 KYB-M3T2B-00 211DC026 PLATE 1
421 KYB-M3T2C-00 211DC027 PLATE 1
422 KYB-M3T2D-00 211DC028 PLATE 1
423 KYB-M3T2E-00 211DC029 PLATE 1
424 KYB-M3T1N-00 0920H14G LEVER 1
425 KYB-M3T1D-00 0920H12E BEARING 1
426 KYB-M3T1E-00 0920H12F COVER 1
427 KYB-M3T1F-00 0920H12G COVER 1
428 KYB-M3T1G-00 0920H12K SPRING 1
429 KYB-M3T1H-00 0920H12L GUIDE 1
430 KYB-M3T1K-00 0920H13F GUIDE 1
431 KYB-M3T1W-00 0920H15K COLLAR 2
432 KYB-M3T1X-00 0920H15L COLLAR 2
433 KYB-M3T1Y-00 0920H15M COLLAR 1
434 KYB-M3T20-00 0920H15N COLLAR 1
435 92012-05010 0920H11N BOLT,BUTTON HEAD 1 BUTTAN M5L10
436 90112-02J008 221AA115 BOLT,HEX.SOCKET HEAD 2 M2L8
437 90990-06J004 221A0231 BOLT,HEX-SCT 10 BUTTAN M3L4
438 KYB-M3T23-00 0920H16Z LOCKING_METAL 2
439 92A08-04004 221CB002 SCREW,SET 2 SET M4L4
440 90990-01J118 0920H158 BOLT,HEX.SOCKET HEAD 12 M1.6L5
441 90990-66J006 221DA218 SCREW,TRUSS HEAD 4 TRS M2L3
442 91312-04025 221AA022 BOLT,HEX.SOCKET HEAD 1 M4L25
443 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 2 M3L8
444 KYB-M4113-00 221HA301 ROHS_WASHER 1 BW3
445 90990-02J020 221CA001 SCREW,SET 1 SET M3L4
