– 106 – E4 5 Air Piping 1509-002 402 404 403 405 406 401 403 See Fig E4-3 Key No.212-02 See Fig E4-4 Key No.312-03 See Fig E4-4 Key No.312-02 See Fig E4-4 Key No.313 See Fig E4-3 Key No.213 to cutter unit T o cutter unit…

– 105 –

POSITIONING SECTION

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

301 KYA-M3J03-00 1005BJ02 BASE_R 1

302 KYB-M3J1B-00 222L0694 GUIDE_LINEAR 1

303 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 16

304 KYA-M3J05-00 1005BJ04 BASE_MOVE_R 1

305 KYA-M3J08-00 10051J2N ASSY,SENSOR FCT2 1 FCT2

306 98502-03008 221DA011 SCREW,PAN HEAD 1

307 KYB-M3J1P-00 213A1568 SHAFT 1

308 95302-06600 221FA011 NUT,HEXAGON 1

309 92902-06200 221HA106 WASHER,PLAIN 1

310 KYB-M3J1S-00 216F0999 PIN_GUIDE 1

311 90990-02J026 221CA007 SCREW,SET 1

312 KYA-M3J0E-00 10051J2X ASSY_VALVE-R 1

312-01 KYA-M3J0S-00 1005BJ22 BRACKET_VALVE_R 1

312-02 KYA-M3J0C-00 10051J2S ASSY,VALVE FCT8,9 1 FCT8,9

312-03 KYA-M3J0B-00 10051J2R ASSY,VALVE CUT2,3 1 CUT2,3

312-04 $AN10-01 1010BJ1Z JOINT 4

312-05 KYB-M3J0E-00 0921A05C VALVE 1

312-06 KYB-M3J0F-00 0921A05D VALVE 1

312-07 KYA-M3J0V-00 1005AB0P JOINT 2

312-08 KYA-M3J0W-00 1005AB0S JOINT 2

312-09 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 4

312-10 92902-05200 221HA105 WASHER,PLAIN 4

313 KYA-M3J09-00 10051J2P ASSY,SENSOR FCT5 1 FCT5

314 91312-08120 221AA151 BOLT,HEX.SOCKET HEAD 2

315 KYB-M3J1J-00 1005AB11 PIPE_FITTINGS 2

316 KYA-M3J0X-00 1005BJ0C HOLDER 1

317 90112-10J025 221AA067 BOLT,HEX.SOCKET HEAD 1

318 92902-10200 221HA108 WASHER,PLAIN 1

319 91312-05008 221AA028 BOLT,HEX.SOCKET HEAD 2

320 KYB-M3J17-00 211DD872 PLATE 1

321 KYB-M3J16-00 211DD870 PLATE 1

322 91312-04012 221AA018 BOLT,HEX.SOCKET HEAD 4

323 KYA-M3J0A-00 10051J2Q ASSY,SENSOR FCT7 1

324 KYA-M3J0Y-00 1005BJ23 BRACKET_AMP 1

325 KYB-M3J2H-00 23G00207 SENSOR-PELEC 1

326 98502-03006 221DA010 SCREW,PAN HEAD 2

327 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 2

1509-002

– 106 –

5 Air Piping

1509-002

402

404

403

405

406

401

403

See Fig E4-3

Key No.212-02

See Fig E4-4

Key No.312-03

See Fig E4-4

Key No.312-02

See Fig E4-4

Key No.313

See Fig E4-3

Key No.213

to cutter unit

To cutter unit

406

403

406

– 107 –

POSITIONING SECTION

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

401 KYA-M3J0U-00 0916D20Q TUBE_D8 2

402 KYB-M8517-00 1005AB0Y PIPE_FITTINGS 1

403 KYC-M185P-00 0921D302 TUBE_D6 2

404 KYB-M8515-00 1005AB0W PIPE_FITTINGS 2

405 KYB-M919J-00 0917C302 TUBE_D6 2

406 KYA-M3J10-00 1005BJ34 TUBE_D6_Y 2

1509-002
