Ultraprint 2000 Hi E Series Illustrated Parts Breakdown/Engineering Drawings 1-122 Optional T actile Sensor Assembly 990305 (1 of 1) 990305 1 2 27 23 20 16 4 24 3 3 17 19 20 9 2 5 22 12 7 25 26 21 20 8 9 10 13 6 18 11 14…
Illustrated Parts Breakdown
1-121
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-122
Optional Tactile Sensor Assembly 990305 (1 of 1)
990305
1
2
27
23
20
16
4
24
3
3
17
19
20
9
2
5
22
12
7
25
26
21
20
8
9
10
13
6
18
11
14
9
Illustrated Parts Breakdown
1-123
Optional Tactile Sensor Assembly 990305 Parts Listing
Key # Part # Description Quantity
1 001907 SLIDE, MODIFIED AIR ACTUATED U-BLOCK 1
2 001758 COVER, TACTILE MOUNT 1
3 6-32 X 3/8" SHCS —
4 6-32 X 3/4" SHCS —
5 001761 HOUSING, TACTILE MOUNT 1
6 001760 HOUSING, FACE TACTILE MOUNT 1
7 000788 BLOCK, SENSOR MOUNT 1
8 P1629 SWITCH, LOW FORCE W/ER TERMINATION 1
9 #4 FLAT WASHER 1
10 4-40 X 5/8" SHCS —
11 000792 ACTUATOR SWITCH 1
12 001755 FLAG, MOTOR 1
13 #2 FLAT WASHER —
14 2-56 X 1/4" SHCS —
15 P2901 FITTING, SPEED CONTROLLER, 5/32" 2
16 001756 FLAG, CYLINDER MOUNT 1
17 001757 MOUNT, SENSOR 1
18 6-32 X 1/4" BHS —
19 P2309 PHOTOMICROSENSOR, BUILT-IN AMPLIFIER 2
20 4-40 X 3/8" SHCS —
21 000789 COVER, SENSOR MOUNT 1
22 P3588 ACTUATOR, LINEAR, CA SHAFT 1
23 4-40 X 1/4" SHCS —
24 P3708 ANCHOR, SPRING 6-32 X .63" 2
25 002023 COVER, TACTILE MOUNT HOUSING 1
26 2-56 X 1/4" FHS —
27 P3976 SPRING 1
quantities are of entire assembly
NS not shown
