Conveyor 4 Ass'y NO. PART NO. PART NAME Q'TY TYPE REMARK 1 2 3 4 5 J7053196C PCB GUIDE R.C 1 J7053196C 6 J6073000536S C-RING(SHAFT) 3 DIA20 7 J2101799 BEARING NUT-SR 2 0135-641081 8 J1301672 BEARING 3 6804 9 J2…
Conveyor 4-2 Ass'y
- 74 -
18
16
17
Conveyor 4 Ass'y
NO. PART NO. PART NAME Q'TY TYPE REMARK
1
2
3
4
5 J7053196C PCB GUIDE R.C 1 J7053196C
6 J6073000536S C-RING(SHAFT) 3 DIA20
7 J2101799 BEARING NUT-SR 2 0135-641081
8 J1301672 BEARING 3 6804
9 J2101798 BEARING HOUSING-SR 2 0135-641080
10
11 J7053223B BRACKET - SENSOR 1 J7053223B
12 J3211033A PHOTOELECTRIC SENSOR 1 BYD50-DDT
13 J2101793 SPLINE PULLEY 3 0135-641075-P1
14 J7153115A RAIL - SENSOR 1 0145-641151
15 J7053224A BRACKET - RAIL 2 0145-641153
16 J7153109B CLAMP REAR FRAME 1 J7153109B
17 J7153107E CONVEYOR REAR FRAME 1 J7153107E
18 J6701037B EDGE CYLINDER 1 CQ2B12-KRC0137-2D
19
20
21
22
23
24
25
26
27 J7053204A SPLINE BRACKET 1 0145-641072
28 J7053046C SENSOR BRACKET-S 2 J7053046C
- 75 -
Test Ass'y
- 76 -
3
4
2
5
1
