Air Ass` y 1 1-5 11.3. FIL T ER AS S’Y(J90 581007 B) No. P ART No. P ART NAME SIZE Qy REMARK 1 J70521023B MIST P ANE L 1 2 J7152027A GROUN D TERM INAL J7152027A 1 3 J67081006A MIST SEP ARA T OR ASS’Y T AC4020 - 04D - R36…

Advanced High Speed Flexible Mounter

11-4

11.2. AIR FRONT ASS’Y(AM03-007229A)

No.

PART No.

PART NAME

SIZE

Qy

REMARK

1

FC09

-

001465A

BKT AI

R F

1

2

J67090012B

REGULATOR

1

3

J1301187

ELBOW FITTING

PL12

-

04/SQL12

-

04S

-

W

2

4

J67111183A

ELBOW MINI FITTING

SCL04

-

01

1

5

AM03

-

007638A

AIR INDICATOR CABLE ASS

’

Y

SM48

-

CV026

-

1

1

6

J6711147A

FITTING

KQ2H04

-

M5/SQL04

-

M5

-

W

1

7

J6009400837

SEMUS NA

BE SCREW

M4*8 (NATURE COLOR)

2

8 J61191172A GAUGE

GZ46

-

K

-

01

-

C1

GZ46-K-01-C

1

9

J61191167A

JOINT

KQ2F04

-

01

1

10

J67091014A

REGULATOR

AR08

-

T2

-

D0M0

-

J346A

1

11

J6012501050

TRUSS SCREW

M5*10 (SUS)

2

AIR TUBE

ø

4*3000mm

1

AIR TUBE

ø

4*300mm

1

J1301187

ELBOW FITTING

J67090012B

REGULATOR

J67111183A

ELBOW MINI

FITTING

FC09-001465A

BKT AIR F

J67111201A

JOINT

AM03-007638A

AIR INDICATOR

J61191172A

GAUGE

J61191167A

JOINT

J67091014A

REGULATOR

J6009400837

REGULATOR

Air Ass`y

11-5

11.3. FILTER ASS’Y(J90581007B)

No.

PART No.

PART NAME

SIZE

Qy

REMARK

1

J70521023B

MIST PANEL

1

2

J7152027A

GROUND TERMINAL

J7152027A

1

3

J67081006A

MIST SEPARATOR ASS’Y

TAC4020

-

04D

-

R3643

1

4

J6001802038

SOCKET HEAD CAP SCREW

M8

*20

2

5

J6042800038

FLAT WASHER

M8

2

6

J6009300637

SEMUS NABE SCREW

M3*6

4

7

MAIN AIR TUBE

ø10*3000mm

1

8

AIR TUBE

ø10*3000mm

2

J6042800038

WASHER

J67081006A

MIST SEPARATOR ASS

’

Y

J6009300637

SEMUS NABE SCREW

J7152027A

GROUND

TERMINAL

J70521023B

MIST PANEL

J6001802038

SOCKET HEAD

CAP SCREW

Advanced High Speed Flexible Mounter

11-6

11.4. AIR VACUUM EJECTROR(AM03-007414A)

No.

PART No.

PART NAME

SIZE

Qy

REMARK

1

FC09

-

001657B

B

KT VAC GEN

1

2 HP11-000058

PUMP

P6010-AK-01-

LA52SG

1

3

J67111205A

FITTING

SQL10

-

02S

1

4

J1300067

SILENSER

1

5 FC28-000103

ADAPTER

ADAPTER M3/4

F1/2(

1

6

FITTING

FITTING KQ2L12-

04S

1

7

AM03

-

005698A

CABLE ASSY-VACUUM_PWR

1

8

J1301213

PLUG

P

LUG [PT 3/8]

1

9

J6012501050

TRUSS SCREW

M5*10

5

10 J67021025A

AIR-VALVE

VP544

-

5D

-

03

-

A

VP544-5DZ1-03-A

1

11

J67111203A

FITTING

SQL10

-

03S

2

12

J6712008A

PLUG

[PT1/8]

1

13

J6001403038

SOCKET HEAD CAP SCREW

M4*30

2

14

HP11

-

000058

FITTING KQ2L04-01S

KQ2L04

-

01S

1

15

J6713019A

AIR TUBE

U2

-

4

-

10*6.5

J67111205A

FITTING

A

HP11-000058

FITTING

A

HP11-000058

FITTING

A

FC28-000103

ADAPTER

A

J6012501050

TRUSS SCREW

A

HP11-000058

VACUUM GENERATOR

A

FC09-001657B

BKT VAC GEN

A

J1300067

SILENSER

J67021025A

AIR VALVE

J6712008A

PLUG

J1301213

PLUG

J67111203A

FITTING

J6001403038

SHCS
