MODEL TCM-X100J 0212-002 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 249 RF-1 5 1 630 109 1488 FUSE HO LDER 3 766RF- 010-051 54 630 085 7917 CI R CU IT P ROT ECT OR 1 Q20 5 766RF-010-054 55 424 005 9408 FU SE 600V …
MODEL TCM-X100J
0212-002
248
200Vޔ100V 㔚Ḯㇱ
200V,100V POWER SUPPLY SECTION
Fig. RF-1 200Vޔ100V 㔚Ḯ 200V,100V Power Supply
91
90
80
89
Fig.RF-1
4797L
TCM-X300
89
90
91
69
69
54
66
59
61
60
.
62
63
.
65
51
.
51
.
67
59
88
89
90
74
73
76
.
56
74
91
75
72
88
72
88
72
97
99
96
68
95
93
92
69
70
69
70
71
59
55
97
96
99
64
MODEL TCM-X100J
0212-002
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
249
RF-1
51 630 109 1488 FUSE HOLDER 3 766RF-010-051
54 630 085 7917 CIRCUIT PROTECTOR 1 Q205 766RF-010-054
55 424 005 9408 FUSE 600V 20A 1 F120 766RF-010-055
56 630 053 8618 EM-CONTACTOR 1 KM2 766RF-010-056
59 630 049 3672 BRACKET,WIRING 3 766RF-010-059
60 630 083 5465 TERMINAL 9 766RF-010-060
61 630 083 5533 ACCESSORY,WIRING 1 766RF-010-061
62 630 072 8408 ACCESSORY,WIRING 1 766RF-010-062
63 630 058 8460 ACCESSORY,WIRING 1 766RF-010-063
64 630 106 1818 PANEL 1 766RF-010-064
65 424 005 9309 FUSE 600V 12A 2 F201,F203 766RF-010-065
66 630 085 7917 CIRCUIT PROTECTOR 1 Q206 766RF-010-066
67 630 083 5564 ACCESSORY,WIRING 1 766RF-010-067
68 630 105 2793 BRACKET 1 766RF-010-068
69 630 071 3343 COVER 6 766RF-010-069
70 630 071 3350 COVER 2 766RF-010-070
71 630 089 6510 RAIL,WIRING 1 766RF-010-071
72 630 048 3833 MECH PARTS(MOUNTING BASES 4 766RF-010-072
73 630 053 8588 EM-CONTACTOR 3 KM3,KM4,KM9 766RF-010-073
74 630 049 3672 BRACKET,WIRING 2 766RF-010-074
75 630 089 6503 RAIL,WIRING 1 766RF-010-075
76 630 100 1357 COMP,CR 3 766RF-010-076
80 630 086 3871 FILTER,NOISE 1 ZNF1 766RF-010-080
88 411 113 7501 SCR TRS 4X10 4 766RF-010-088
89 411 043 5004 SCR PAN 4X8 8 766RF-010-089
90 411 008 1706 WASHER SPR 4 8 766RF-010-090
91 411 119 2104 WASHER V 4X9X0.8 8 766RF-010-091
92 630 000 7626 BOLT,HEX-SCT 2 766RF-010-092
93 411 141 2905 WASHER SPR 4 2 766RF-010-093
95 630 001 0213 WASHER 2 766RF-010-095
96 630 000 7756 BOLT,HEX-SCT 4 766RF-010-096
97 411 141 6705 WASHER SPR 5 4 766RF-010-097
99 630 001 0220 WASHER 4 766RF-010-099
MODEL TCM-X100J
0212-002
250
ࠪࠤࡦࠬࡄࡀ࡞ㇱ RELAY SEQUENCE PANEL SECTION
Fig. RG-1 ࠪࠤࡦࠬࡄࡀ࡞ Relay Sequence Panel
72
73
.
65
72
95
96
94
92
97
98
99
58
A
C
B
A
B
57
54
58
99
59
98
97
99
52
98
71
86
92
88
90
87
97
55
.
56
.
70
69
51
68
97
98
99
60
66
63 64
.
93
67
92
85
93
92
67
79
Fig.RG-1
4797L
TCM-X300
C
95
96
89
78
74
