ASYMTEK Spectrum® ll S2-900 Spares List
March 2024 5
FRU,X-BEAM Y-AXIS PULLEY KIT,SL-
940/1040
SCREW, M3 X 0.5 SOCKET X 8
6
387980
NUT,HEX M6X1.0,SS
20
388086
WASHER, FLAT M6
15
388088
ASSY,RIGHT REAR PULLEY
1
7209871
ASSY,LEFT REAR PULLEY
1
7209872
ASSY,LEFT FRONT PULLEY
1
7209873
ASSY, RIGHT FRONT PULLEY
1
7209874
BRKT.Y SWITCH
1
7211486
SCREW M6X1.0 BUTTON X12,SS
4
7252899
ASSY,Y CARRIAGE PULLEY
2
7209875
SCREW,M6 X 1.0 SOCKET X 16
5
7243615
FRU, X-BEAM X-AXIS PULLEYS KIT, SL-
940
ASSY,CM X-CARRIAGE PULLEY
1
7209876
SCREW,M6 X 1.0 SOCKET X 16
4
7243615
ASSY,IDLE PULLEY
6
7213248
SCREW, M6X50, SOCKET, BO-ST
3
7268291
SHIM, SHORTENING, 1/4IDX.03THK
6
387950
SPACER, ALUM., 1/2OD,1/4ID X 1
2
387930
SCREW,M6X1.0,SOCKET
CAP,X40,SS
2
7268290
SPACER,.50OD X .25ID X .31LG
2
7207573
FRU,XY DRIVE,SL-940
ASSY,CM XY DRIVE
1
7241338
SCREW, M6X10, SOCK, CAP, SS
5
388099
FRU, FRONT PANEL KIT,S2&Q68
SWITCH,EMO ACTUATOR
1
198870
WASHER, FLAT M4
1
387998
SCREW, M3X.05 FLAT
1
392120
LABEL,E-STOP,16mm
1
7209411
BUSHING,OPEN/CLOSED,1.09D
1
7209414
PLUG,DOME,1.093 DIA,BLACK
1
7209415
SNAP,ESD FEMALE
1
7209416
GUARD,EMO CMP
1
7210753
SWITCH,EMO CONTACT BLOCK
1
198871
SWITCH,3P-NO,MOM,24V
LED,GREEN
1
7204788
SWITCH,2P-NC,MOM,BLACK FLUSH
1
7204789
USB-A MALE TO USB-A FEM,PNL MT
1
7225734
JACK,BANANA,INSULATED BLACK
1
7257497
NUT,M4,W/LOCKWASHER,ZPL-ST
1
7208192
FRU,BLKHD Q-DS KIT,S2&Q68
FITNG,Q-D BLKHD FEM 10-32 BLUE
2
195401
FITNG,Q-D BLKHD FEM 10-32 BLK
2
195402
FITTING,Q-D BLKHD,CPC
2
195525
FITT'G, 1/4Q-DISC X 10-32 UNC
2
383010
FITNG,Q-D BLKHD FEM,M5 CLEAR
2
7209918
FITNG,Q-D BLKHD FEM,GREEN
2
7201192
FTG,MINI,FEM,BULKHEAD DUAL
2
7221822
FRU,CONV MANIFOLD ASSY KIT, S2
PLUG,1/8 QUICK DISCONNECT
8
7220173
ASSY,MFLD,4 VALVE 4-W,6 PORT
1
6114635
PLUG, ONE TOUCH
2
383428
FRU, VACS/PURGE/HS VALVES KIT, S2
VALVE, 3 WAY, 24V
2
382928
MUFFLER, 1/8 MPT
2
6114637
FITTING, ELBOW,1/8NPT-1/4TUBE
1
387432
ELBOW,90 SWIV.-1/8TUBEX1/8 NPT
1
387424
FIT'G,BRANCH
TEE1/4TUBEX1/8MPT
1
387448
FITTING,1/8NPT X DUAL-Y 1/4OD
1
392803
PLUG, ONE TOUCH
1
383428
ASYMTEK Spectrum® ll S2-900 Spares List
March 2024 6
ASSY,VALVE,3 WAY
W/FITTINGS/MUFFLER
1
6114645
ASSY,VALVE,3WAY
W/FITTINGS/MUFFLER/CRIMP
1
6114646
FRU, MAIN MAC VALVE KIT, S2
VALVE, 3 WAY, HIGH FLOW
2
383240
FITTING, ELBOW, 3/8 TUBE OD
2
383432
FITTING, 1/8M X 1/8F X 1/8FNPT
2
7244870
FITTING,MALE,3/8TUBE X1/8 NPT
2
7243915
FITTING, ELBOW,1/8NPT-1/4TUBE
1
387432
FITTING,1/8NPT X DUAL-Y 1/4OD
1
392803
MUFFLER, 1/8 MPT
2
6114637
LABEL,BLANK,COMPONENT,SMALL
2
7220558
FRU, PNEU MAC VALVES KIT, S2
VALVE, 4 WAY AIR, 24V
1
382933
MUFFLER, 10-32 UNC
1
382934
ELBOW, 10-32 X 1/4 HOSE,SWIVEL
3
382935
ASSY,VALVE,3 WAY W/FITTINGS
1
6114644
ASSY,VALVE,3 WAY
W/FITTINGS/MUFFLER
2
6114645
ASSY, HUB&POWSUP, E14, S2
VELCRO,1" WIDTH,BLACK
0.5
7246604
CABLE TIE,4",BLACK
10
382767
CLIP,WIRE HARNESS,1"DIA
1
7226307
NUT, HEX M4 X 0.7
1
7243842
SCREW, M4 X 0.7, SOCKET CAP,X8
1
388026
FERRITE,SNAP-ON,7MM DIA
1
7245729
WIRE MARKERS,10AWG,#6
2
6105102
WIRE MARKERS,10AWG,#7
1
7257507
ADAPTER,USB TO CAN
1
7205214
PLATE,600W POWER
1
7209409
CABLE,LAPTOP AC POWER
1
7243488
CABLE,CAN INTERFACE STP
1
7246630
CABLE-P, USB, 6FT,REVERSIBLE A
TO B
1
6133114
LABEL,BLANK,SELF LAMINATE
2
7220555
ADAPTOR,FTDI,RS232-USB
1
7253995
ADAPTER,USB TO ETHERNET
1
7296110
HUB,USB,2.0,7 PORT
1
7296111
CBL TIE,STD,BLACK,24",HK & LP
1
7296112
CABLE,USB EXT,6FT,RIGHT ANGLE
1
7296808
ASSY,LIGHT BOX VOF
BAG,SEALTOP4X6,2 MIL,W/WHT
1
7257493
CABLE TIE, 3/16" ROUND
1
387910
SCREW,M2X.40X6 FLTHD. PH. REC.
4
387957
SCREW,M2.5X6MM SOCK HD.CAP
4
387959
SCREW,M2-0,4X6 SOCKET CAP
4
7275113
SCREW, M3X.05 FLAT
1
392120
ASSY,RGB LED
1
7213695
BLOCK,VOF LIGHT BOX
1
7214491
SETTING,STAR LED LIGHTBOX
1
7214492
BLOCK,BEAMSPLITTER LIGHTBOX
1
7214493
LENS,FRESNEL,RECT.LIGHTBOX
1
7214495
DIFFUSER,RECT.LIGHTBOX
1
7214496
BEAMSPLITTER,VOF LIGHTBOX
1
7214512
SCREW,FLAT,M2 X 0.4 X 4SST
2
7217764
PAPER,FLOCKED,BLACK
3
6126542
HOLDER,OPTICS,VOF
2
7217763
ASSY,S-9XX SERVICE STATION STD
BOOT,VAC .120 ID OLIVE
1
381523
BUSHING,TACTILE SENSOR
1
194541
DISPENSE CARD,30MM SQ
1
194544
COVER,PURGE CUP,CLEAR
1
194701
FITTING,1/8NPT X DUAL-Y 1/4OD
1
392803
PLUG, ONE TOUCH
1
383428
ASYMTEK Spectrum® ll S2-900 Spares List
March 2024 7
O-RING, 1 7/8 OD X 1/16
1
381649
CABLE CLAMP, 1/8" ROUND BLACK
1
7244930
SCREW, M4X0.7, BUTTON HEAD, X8
2
388040
SCREW, M5X25 CUP END SET, SS
1
7275147
SWITCH, ULTRA-PRECISION
1
383514
HEATSHRINK,3/16",2:1,BLACK
1
6126525
SOCKET,26-30AWG,MOLEX
MICROFIT
3
7202784
PLUG-M,3S,MOLEX MICROFIT
1
7202794
SCREW,THUMB,M3X16MM
2
7203341
CLAMP,DISP.TILE SPRING
1
7214905
BASE,VALVE STATION
1
7220835
ASSY,Z TACTILE,CERAMIC INSERT
1
7224748
KIT,SPECTRUM CONSUMABLES
BOOT,VAC.045 ID GREEN
10
383818
BOOT,VAC .020 ID ORANGE
10
381521
BOOT,VAC .031 ID PINK
10
381522
BOOT,VAC .120 ID OLIVE
10
381523
WIPER,BANJO SHORT 1.25"
5
381536
CUP,DIXIE,1 OZ (PKG OF 200)
1
388857
KIT, CAMERA CARE
1
383698
ASSY,NEEDLE X-Y LOCATOR
1
392435
POLYCON,MINI
1
602209
SCALE CUP W/CENTER POST
5
7225481
FRU, ASSY,Z-HEAD,S2-9XX
BAG, SEALTOP 2X3, 2 MIL, W/WHT
8
382053
BAG, SEALTOP 6 X 9, .002 MIL
1
7274452
WASHER, FLAT M4
6
387998
SCREW, M4X0.7 SOCKET FLAT X 10
10
7245171
SCREW, M4 X 0.7, SOCKET X 10
4
388027
SCREW, M4 X 0.7, SOCKET X 12
15
388029
SCREW,M4X0.7 BUTTON HEAD,X6
3
7226304
ASSY,Z-HEAD,S2-9XX
1
7254770
COVER,MOD Z-HEAD,LHS,S2
1
7254764
SCREW,SHC,FLATHD,M4.0.7X8MM,
SS
2
7228081
SCREW, M4X0.7X25MM SHCS, SS
2
388033
SCREW, M4X0.7, BUTTON HEAD, X8
3
388040
ASSY,LIFT TABLE,S-9XX
PLUG, NYLON LIFT MODULE
ENCAP
1
7244649
PIN,LOCATING,LIFT TABLE
2
7213303
SCREW,FLAT,M10X1.5X25MM,SOC,
SS
1
193847
NUT PLATE,LIFT TABLE
1
193854
TUBING,170ID X .250OD,POLYURE
1
6126523
FITTING,1/8MNPT X QD CPC
1
392795
BLOCK, PILLOW, 3/8 ADJUSTABLE
1
381634
ELBOW,90 SWIV.-1/8TUBEX1/8 NPT
2
387424
FITTING, 1/8NPT STREET ELBOW
1
382969
UNION, 1/4" Q-DISC.
1
382989
GREASE, USDA-H1, NLGI-2
1
382186
SCREW, M3 X 10MM, SOCKET CAP
4
387981
SCREW, M3X.5X16 SOCKET HEAD
2
387983
SCREW,M3X20,SOCK.HD.CAP,SS
2
387984
SCREW M5X20MM FLAT H.
PHILLIPS,SS
4
7244126
SCREW,M5X.8X8 SHCS
1
7245989
SCREW, M5X0.8, SOCKET CAP, X12
4
388065
SCREW, M5X20MM SHCS SS
4
7243426
SCREW,M5-08X25 SOCKET CAP
1
7242064
SCREW,M5-.8X10,SOC SET-CUP,SS
4
7275145
SCREW, M6X1.0, FLAT TIP SET,X8
1
7275156
SCREW,SET,CUP POINT,M6-
1X30,SS
1
7200457
