BASE SYSTEM 3-28 AP Excel Series Drawings Guide Computer Assembly 1011277 1011125 1011277 P3676 PC-271
. . . . .
BASE SYSTEM
AP Excel Series Drawings Guide 3-27
Worknest Assembly AP25-21 (1) Parts Listing
Key No. Part No. Description Quantity
1 P0050 WASHER, FLAT, 13/64 ID X 1/2 OD X 3/32 W 4
2 A2-1550 VACUUM TUNNEL SCREEN 1
3 A2-202 VACUUM TUNNEL ADAPTER 1
4 A2-201 VACUUM TUNNEL 1
5 P5846 BUMPER, RUBBER, 3/8 ID X 5/8 1
6 P0619 CABLE TIE (NOT SHOWN) 10
BASE SYSTEM
3-28 AP Excel Series Drawings Guide
Computer Assembly 1011277
1011125
1011277
P3676
PC-271
. . . . .
BASE SYSTEM
AP Excel Series Drawings Guide 3-29
Computer Assembly 1011277 Parts Listing
Key No. Part No. Description Quantity
P3676 BOARD, DIGITAL, I/O, 120 PT 1
P9043 BOARD, PCA, AXIS MOTION CONTROLLER 1
1010480 SOFTWARE KIT, V8.1.0, CD, APEXCEL/UP2000NT 1
1011125 COMPUTER, SBC, P3, LAN, XGA, PGC PS, WIN NT, ASSY 1
P6031 PCB, 6 CH. ANALOG OUTPUT, 12 BIT, W/DIGITAL I/O 1
P7672 FRAME GRABBER, PCI-BUS, 2MB ON-BOARD VRAM 1
1001922 SOFTWARE DISK, TEST, BLANK, 3.5 1
