4.
LOAD WIRING DIAGRAM OPTION
負荷配線図 オプション
4-7 POWER UNIT(ELECTRIC PARTS)
パワーユニット(制御部品)
EJM8DB-10-407-00
CP1
-T001
TE1N-800-GN/TD-16785-A
PRI_200V CPTL
PRI_0 CPTN
TAISEI DENKI
-F201
R.A.V-781BWZ-4
BK
BK
GN/YE
OKAYA
LX131
AI 2,5-10 BU
PHOENIX CONTACT
NX131
1aF101
TMEE2-5
NICHIFU
3aF101
4aF101
L
2aF101
TMEE2-5
NICHIFU
AC200V
IN
R1.25-4
JST
PRI0T001
P200T001
AI 2,5-10 BU
PHOENIX CONTACT
CPTNT001
CPTLT001
AI 2,5-10 BU
PHOENIX CONTACT
PE
N
L
-X131
TB-X131(F000069)
1 1
2 2
3 3
PHOENIX CONTACT
N
-F101
NF100-SRU 2P 5A
(5A)
1 2
3 4
Mitsubishi Electric
R2-4
JST
AH-6 ORANGE AWG1
N610126564AA
N610126565AA
N610126566AA
R2-4
JST
R2-4
JST
R2-4
JST
R2-4
JST
R2-4
JST
R2-4
JST
R2-4
JST
N610126568AA
N610126567AA
N610126569AA
Flexible Conveyor
Station control
Upper side
Front Base
Flexible Conveyor
Station control
Upper side
Middle Base
Flexible Conveyor
Station control
Upper side
Rear Base
1
NF50-SWU 2P 5A
2
2
2
-X001
N510013514AA
Asada Metal Industry
2
Panasonic Factory Solutions Co.,Ltd. パナソニック ファクトリーソリューションズ株式会社
Name
Drawing No.
Loc. No.
F4K1020-05A
1
2 3 4 5 6 7 8
A
B
C
D
E
F
1 2 3 4 5 6 7 8
A
B
C
D
E
F
Page. No.
POWER UNIT(Electric Parts):NPM-D
AC input
N610130584+002AD
P002
UL1015 14AWG GN/YE GN/YE
UL1015 14AWG GN/YE GN/YE
UL1015 14AWG GN/YE GN/YE
UL1015 14AWG GN/YE GN/YE
UL1015 14AWG BK BK
UL1015 14AWG BK BK UL1015 14AWG BK BK
UL1015 14AWG BK BK
L11 P003-2A
N11 P003-2B
E(T001) P003-2B
E(X132) P003-2B
