I/O Map >> Standard Input and Output Signals
SYS-CP842-1.0E 6-5
X06A PANEL UNLOADING
CONFIRMATION
Panel unloading confirmation Panel present: O
X06B MCID CONVEYOR MCID conveyor presence MCID present: O
X06C MCID CONVEYOR SPEED
DECELERATION POINT
MCID conveyor deceleration position Panel present: O
X06D MCID CONVEYOR PANEL ARRIVAL
CHECK
MCID conveyor panel arrival Panel present: O
X06E MCID REVERSE CONVEYOR speed
DECELERATION POINT
MCID reverse conveyor deceleration
position
Panel present: O
X06F MCID REVERSE CONVEYOR PANEL
ARRIVAL CHECK
MCID reverse conveyor panel arrival Panel present: O
X070 MCID CONVEYOR WIDTH MOTOR
+OT
MCID conveyor width motor (+)
overtravel
Dog engaged: X
X071 MCID CONVEYOR WIDTH MOTOR -
OT
MCID conveyor width motor (-)
overtravel
Dog engaged: X
X072 MCID CONVEYOR WIDTH INCHING
+
MCID conveyor width motor (+)
inching
Button on: O
X073 MCID CONVEYOR WIDTH INCHING - MCID conveyor width motor (-) inching Button on: O
X074 MCID CONVEYOR + FOLLOW
CHECK
MCID conveyor follow-up check (+)
X075 MCID CONVEYOR - FOLLOW
CHECK
MCID conveyor follow-up check (-)
X076 MCID CONVEYOR STOPPER
UPPER LIMIT CHECK
MCID conveyor stopper upper limit Stopper engaged: O
X077 MCID CONVEYOR STOPPER
LOWER LIMIT CHECK
MCID conveyor stopper lower limit Stopper disengaged: O
X078 MCID REVERSE CONVEYOR
STOPPER UPPER LIMIT CHECK
MCID reverse conveyor stopper upper
limit
Stopper engaged: O
X079 MCID REVERSE CONVEYOR
STOPPER LOWER LIMIT CHECK
MCID reverse conveyor stopper lower
limit
Stopper disengaged: O
X07A MCID PANEL TRAN 3 MCID panel transported check 3 Panel present: O
X07B BACKUP PIN CHECK Backup pin check Back-up pin present: O
X07C X AXIS FAN ALARM X-axis fan alarm Error: X
X07D SEQUENCER DATA SIGNAL (D1) Sequencer data signal (D1) Signal: O
X07E SEQUENCER DATA SIGNAL (D2) Sequencer data signal (D2) Signal: O
X07F D1 CAM CYLINDER LOWER LIMIT
CHECK
D1 Cam cylinder lower limit Pallet lowered: O
X080 D1 TABLE STOPPER LOCK CHECK D1 table stopper lock Stopper raised: O
X081 D1 TABLE STOPPER UNLOCK
CHECK
D1 table stopper unlock Stopper lowered: O
X082 D1 PCU CLAMP CHECK (1) D1 Panel change unit clamp check 1 Clamped: O
X083 D1 PCU UNCLAMP CHECK (1) D1 Panel change unit unclamp check 1 Unclamped: O
Address Signal Name Description Signal Status at I/O
Screen
I/O Map >> Standard Input and Output Signals
6-6
SYS-CP842-1.0E
X084 D1 PCU CLAMP CHECK (2) D1 Panel change unit clamp check 2 Clamped: O
X085 D1 PCU UNCLAMP CHECK (2) D1 Panel change unit unclamp check 2 Unclamped: O
X086 D1 PALLET ARRIVE CHECK D1 Pallet Arrival Pallet present: O
X087 D1 PALLET SETTING CHECK (1) D1 Pallet set check 1 Pallet present: O
X088 D1 PALLET SETTING CHECK (2) D1 Pallet set check 2 Pallet present: O
X089 D1 PALLET CONFIRMATION
SENSOR
D1 Pallet confirmation sensor
X08A D1 PALLET PASS CHECK (1) D1 Pallet pass check 1 Pallet present: O
X08B D1 PCU SET CHECK D1 Pallet change unit set Pallet Change Unit Set:
O
X08C D1 CAM CYLINDER UPPER LIMIT
CHECK
D1 Cam cylinder upper limit Pallet raised: O
X08D D1 PALLET PASS CHECK (2) D1 Pallet pass check 2 Pallet present: O
X08E PCU1 CLAMP PCU1 Clamp Clamped: O
X08F PCU1 UNCLAMP PCU1 Unclamp Unclamped: O
X090 D2 AXIS FAN ALARM D2 axis fan alarm Error: X
X091 Not used
X092 CP842 SELECT
CP842 select CP842: O
X093 D2 PARTS SET COMPLETE D2 parts set complete Part setting complete:
O
X094 D2 PARTS SET CANCEL D2 parts set cancel Part setting cleared: O
X095 D2 CAM CYLINDER LOWER LIMIT
CHECK
D2 Cam cylinder lower limit Pallet lowered: O
X096 D2 TABLE STOPPER LOCK CHECK D2 table stopper lock Stopper raised: O
X097 D2 TABLE STOPPER UNLOCK
CHECK
D2 table stopper unlock Stopper lowered: O
X098 D2 PCU CLAMP CHECK (1) D2 Panel change unit clamp check 1 Clamped: O
X099 D2 PCU UNCLAMP CHECK (1) D2 Panel change unit unclamp check 1 Unclamped: O
X09A D2 PCU CLAMP CHECK (2) D2 Panel change unit clamp check 2 Clamped: O
X09B D2 PCU UNCLAMP CHECK (2) D2 Panel change unit unclamp check 2 Unclamped: O
X09C D2 PALLET ARRIVE CHECK D2 pallet arrival Pallet present: O
X09D D2 PALLET SETTING CHECK (1) D2 pallet set check 1 Pallet present: O
X09E D2 PALLET SETTING CHECK (2) D2 pallet set check 2 Pallet present: O
X09F D2 PALLET CONFIRMATION
SENSOR
D2 Pallet type confirmation sensor
Address Signal Name Description Signal Status at I/O
Screen
I/O Map >> Standard Input and Output Signals
SYS-CP842-1.0E 6-7
Input-3
Address Signal Name Description Signal Status at I/O
Screen
X0A0 D2 PALLET PASS CHECK (1) D2 Pallet pass check 1 Pallet present: O
X0A1 D2 PCU SET CHECK D2 Pallet change unit set Pallet Changed Unit
Set: O
X0A2 D2 CAM CYLINDER UPPER LIMIT
CHECK
D2 Cam cylinder upper limit Pallet raised: O
X0A3 D2 PALLET PASS CHECK (2) D2 Pallet pass check 2 Pallet present: O
X0A4 PCU2 CLAMP PCU2 Clamp Clamped: O
X0A5 PCU2 UNCLAMP PCU2 Unclamp Unclamped: O
X0A6 D1 AXIS FAN ALARM D1 axis fan alarm Error: X
X0A7 Not used
X0A8 Not used
X0A9 IN-CONVEYOR 2ND PANEL
STOPPER UPPER LIMIT CHECK
In-conveyor 2nd panel stopper upper
limit
Stopper raised: O
X0AA IN-CONVEYOR 2ND PANEL
STOPPER LOWER LIMIT CHECK
In-conveyor 2nd panel stopper lower
limit
Stopper lowered: O
X0AB IN-CONVEYOR 1 SPEED
DECELERATION POINT
In-conveyor 1 panel deceleration
position
Panel present: O
X0AC IN-CONVEYOR 1 PANEL ARRIVAL
CHECK
In-conveyor 1 panel arrival Panel present: O
X0AD IN-CONVEYOR 2 SPEED
DECELERATION POINT
In-conveyor 2 panel deceleration
position
Panel present: O
X0AE IN-CONVEYOR 2 PANEL ARRIVAL
CHECK
In-conveyor 2 panel arrival Panel present: O
X0AF PANEL INTERVAL BETWEEN IN-
CONVEYOR 1 AND 2
Panel interval between in-conveyor 1
and 2
Panel present: X
X0B0 IN-CONVEYOR PANEL IN CHECK In-conveyor panel loaded Panel present: O
X0B1 IN-CARRIER FORWARD LIMIT
PANEL CHECK (1)
In-carrier advance end panel check 1 Panel present: O
X0B2 IN-CARRIER FORWARD LIMIT
PANEL CHECK (2)
In-carrier advance end panel check 2 Panel present: O
X0B3 IN-CARRIER FORWARD LIMIT
CHECK
In-carrier advance end Advanced limit: O
X0B4 IN-CARRIER RETRACT LIMIT
CHECK
In-carrier retract end Retracted limit: O
X0B5 IN-LIFTER UPPER LIMIT CHECK In-lifter upper end Upper limit: O
X0B6 IN-LIFTER LOWER LIMIT CHECK In-lifter lower limit Lower limit: O
X0B7 IN-CARRIER RETRACT LIMIT
CLAMP CHECK (FIXED RAIL)
In-carrier retract end clamp
(Fixed rail)
Carrier closed: O
X0B8 IN-CARRIER RETRACT LIMIT
CLAMP CHECK (ADJUSTABLE RAIL)
In-carrier retract end clamp
(Adjustable rail)
Carrier closed: O
