KMF-1706 2,3 10 6 11 4 7 1 9 5 8 2,3 10 6 11 4 7 1 9 5 8 5 1 System Parts System Parts
KMF-1706
No. Part No. Part Name Q’ty Remarks Rank Level
1 $SSU4 SPEED CONTROLLER 2
2 90990-27J002 BEARING 1
3 90K81-200004 CAP C4 11
4 KB0-M2216-00 WASHER 1 2 /
Í
5 KB0-M2255-01 PULLEY 5 1 /
Í
6 KB2-M2254-00 PULLEY 4 1 /
Í
7 KC0-M1751-00 PULLEY 1 1 /
Í
8 KH2-M1807-00 BOLT DRIVEN PULLEY 1 /
Í
9 KH2-M1815-00 DAMPER 2 /
Í
10 KKL-M1825-00 BELT 1 /
Í
11 KKL-M1865-00 BELT 1 /
Í
12 KKU-M1836-01 PLATE SENSOR 2 /
Í
13 KMF-M1816-00 PLATE H AXIS 1 /
Í
14 KMF-M1818-00 PLATE H AXIS 2 1 /
Í
15 KMF-M1822-00 BRACKET GUIDE HOOK 1 /
Í
16 KMF-M1823-00 HOOK BASE GUIDE 1 /
Í
17 KMF-M1824-00 BRACKET MOTOR 1 /
Í
18 KMF-M1832-00 GUIDE CABLE 1 /
Í
19 KMF-M1865-00 TAPE 1 DUCT 1 L=440mm /
Í
20 KMF-M1866-00 TAPE 2 DUCT 1 L=500mm /
Í
21 KMF-M1867-00 BRACKET TAPE 2 /
Í
22 KMF-M18A2-00 HAND ASSY. 1 B
Í
23 KMF-M18A5-00 GUIDE HOOK 1 /
Í
24 KMF-M653J-00 SEN.HOOK PLT ASSY 2 B
Í
25 KV9-M1843-00 PLATE BELT NUT 1 /
Í
26 KW4-M1820-00 BRACKET PULLY 1 1 /
Í
27 KW4-M1821-00 BRACKET PULLY 2 1 /
Í
28 KW4-M1826-00 BELT MOTOR 1 /
Í
29 KW4-M1846-00 SPACER GUIDE 5 /
Í
30 $NK-2N NYLON CLIP 3
31 90112-02J010 BOLT HEX SOCKET HEAD 4
32 90171-02J026 WASHER PLAIN 4
33 90933-03J696 BEARING 4
34 90990-11J003 SCREW PAN HEAD W/W 3
35 90990-31J008 BOLT SHOULDER 1
36 90990-41J004 COLLAR 1
37 90990-41J005 COLLAR 1
38 90990-41J050 COLLAR 1
No. Part No. Part Name Q’ty Remarks Rank Level
39 90K65-002234 AC SERVO MOTOR 1 B
Í
40 91312-03006 BOLT HEX SOCKET HEAD 8
41 91312-03010 BOLT HEX SOCKET HEAD 8
42 91312-03025 BOLT HEX SOCKET HEAD 1
43 91312-04012 BOLT HEX SOCKET HEAD 17
44 91312-05010 BOLT HEX SOCKET HEAD 6
45 91312-05012 BOLT HEX SOCKET HEAD 2
46 91312-06010 BOLT HEX SOCKET HEAD 4
47 92902-04600 WASHER PLAIN 1
48 92902-05200 WASHER PLAIN 4
49 92A08-04304 SCREW SET 2
50 95602-05100 NUT S/L 2
51 95602-06100 NUT S/L 1
52 98702-03006 SCREW FLAT HEAD 4
53 98702-04008 SCREW FLAT HEAD 13
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
4
2
Drive
Hook
KMF-1706
2,3
10
6
11
4
7
1
9
5
8
2,3
10
6
11
4
7
1
9
5
8
5
1
System Parts
System Parts
KMF-1706
No. Part No. Part Name Q’ty Remarks Rank Level
1 KGS-M4574-01 INDI CTRL BOARD ASSY 1 /
Í
2 KGW-M4578-01 INDICATOR BOARD ASSY 1 Red Color /
Í
3 KGW-M4578-12 INDICATOR BOARD ASSY 1 Three Colors /
Í
4 KHY-M537F-00 SAFETY RELAY 1 B
Í
5 KLA-M4476-25 FDR.CTRL.BRD.ASSY. 1 /
Í
6 KLW-M65NA-00 HNS SELECT 1A 1 /
Í
7 KLF-M537G-20 CONTACTOR 1 1 B
Í
8 KHF-M5126-A0 SAFETY SWITCH ASSY 1 B
Í
9 KLF-M537G-40 CONTACTOR 1 1 B
Í
10 KMF-M6523-00 RELAY SOCKET 1 /
Í
11 KMF-M6521-00 RELAY RJ1S D24 1 B
Í
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
No. Part No. Part Name Q’ty Remarks Rank Level
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
5
1
System Parts
System Parts
