Components changeover table F4/F5-HM mobile prod. Lift
Page 15 / 17 19.11.2021
Pos. Item no. Description Part marking
LEVER COMPLETE
49 00341881-01 S20 COMPONENTS TABLE
ACTUATOR TUBE
50 00845023-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 6-8.8
51 00357732-01 SPACER
52 00357647-01 WHEEL FORK
53 00048338-01 WASHER
54 00845086-01 HEXAGON SOCKET HEAD CAP
SCREW M8 X 80-8.8
55 00359485-01 FLANGE SLEEVE 20*15/15*1-8
56 00311958-01 ADJUSTING SHIM 8*14*1.5
57 00322618-01 ADJUSTING SHIM 8*14*1
58 00309319-01 ADJUSTING SHIM
59 00359486-01 COUNTERSUNK SCREW M8*60
60 00343755-01 S20 COMPONENTS TABLE HANDLE
COMPLETE LEFT SIDE
61 00344564-01 S20 COMPONENTS TABLE CONSOLE
COMPLETE LEFT SIDE
62 00619855-01 PARALLEL PIN
63 00345060-01 O-RING 24X3 (NBR) WEAR PART
64 00359409-01 PEDESTAL
65 00359408-01 BRACKET
67 00359406-01 MOUNT LEFT INSIDE F. LOCKING
PLATE
68 00304704-03 SLEEVE SPARE PART
69 00201033-01 PLASTIC SPRING 8,5*20*40 (90
SHORE) RED
SPARE PART
70 00845063-01 DIN912-M6 X 40-8.8 STANDARD PARTS
71 00323576-01 HEXAGON NUT M6
72 00359407-01 STRIP
73 00095086-01 HEXAGON SOCKET HEAD CAP
SCREW
74 00344497-01 S20 COMPONENTS TABLE HANDLE
COMPLETE RICHT SIDE
75 00344565-01 S20 COMPONENTS TABLE CONSOLE
COMPLETE RICHT SIDE
76 00619855-01 PARALLEL PIN
Components changeover table F4/F5-HM mobile prod. Lift
Page 16 / 17 19.11.2021
Pos. Item no. Description Part marking
77 00345060-01 O-RING 24X3 (NBR) WEAR PART
78 00361857-01 MOUNT RIGHT INSIDE F. LOCKING
PLATE
79 00357674-01 WHEEL D=75 B=35
80 00341942-01 GUIDE ROLL LDA-VPA 50K-EL SPARE PART
81 00316265S05 COMMUNICATION SYSTEM SIPLACE
80S
SPARE
82 00328703-01 CABLE : COMP. TABLE - LED SMD SPARE PART
83 00357042-01 COMPONENTS TABLE WASTE
CONTAINER PROD.LIFT
84 00340997-01 S20 COMP.TABLE BELT CONTAINER Spare Part
85 00340998-01 S20 TAPE CONTAINER FRAME
86 00341000-01 S20 TAPE CONTAINER GRID ANGLE
87 00341184-01 S20 TAPE CONTAINER ROLLER AXIS
88 00343523-01 S20 COMPONENTS TABLE GRID
TRIANGLE
89 00337424-01 S50 TAPE CONTAINER PARTITION
PLATE
SPARE PART
90 00318154-01 DIN EN ISO 7380-M8 X 12-12.9
91 00306939-01 DIN 7337 - A 4 X 8-AL
92 00845075-01 HEXAGON SOCKET HEAD CAP
SCREW M8*16
93 00845058-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 16-8.8, COPPER + NI-
PLATED
94 00346360-01 DIN 923 M6 X 10-A2-70 STANDARD PARTS
95 00845025-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 10-8.8
96 00343356-01 S20 COMPONENTS TABLE COVER
PLATE
97 00344637-01 COMP. FEED. CHANGEOV. TABLE
S20 COVER
Spare Part
98 00343183-02 COMPONENTS TABLE LIST BOX SPARE PART
99 00343842-01 S20 COMPONENTS TABLE ROLL SPARE PART
100 00342324-02 BOWDEN WIRE SPARE PART
101 00332779S03 EMPTY TAPE GUIDE CHANNEL
COMPL.HIGH 15MM
SPARE PART
102 00337047-02 GUIDE METAL S23 SPARE PART
103 00309754-01 DISTANCE SLEEVE 5.6*8*10 ST
NICKLE-PL.
SPARE PART
