OUR ALLY IN TECHNOLOGICAL DISCOVERY, ALWAYS.
The Desktop Robot Series is designed to deliver
accuracy and reliability. Its desktop robots are robust,
fast and accurate in performance.
ACCURATE AND RELIABLE HARDWARE
DESIGN
All desk top robots are designed for high accuracy
and long term reliability through using high quality
components and machined parts. Both the A and
B series are applicable for used in development,
prototyping as well as production.
Desktop Robot
Series
Advanced Dispensing
Desktop Robot
SUPREME VISION ALIGNMENT
TECHNOLOGY
In addition to typical corner finder or template
comparison, Stream Vision software filters can handle
difficult image processing to ensure precise alignment.
Y
OUR ALLY IN TECHNOLOGICAL DISCOVERY, ALWAYS.
VERSATILE DISPENSING APPLICATORS FOR
ALL PRECISION APPLICATIONS
Different fluids and applications need different dispensing
applicators to meet the challenge of watery, thick or
streaming materials for wide range of dot sizes, line width
and dispensing heights.
Piezo jet valve for high speed jetting
Progressive Cavity Pump (PCP) for precision high
viscosity contact dispensingviscosity contact dispensing
Deposition pump for < 100μm dispensing
Solder paste jetting valve
Thin film ultrasonic spray coater
10:1 high precision mixing and dispensing
High precision air spray
OPTIONS
Laser height detection for high reflection glass
Universal nozzle cleaning device
Micro scale for dispensing weight calibration
low fluid level detection
1:1~10:1 high precision mixing and dispensing systems
Model 400 Series Robot
Specications :
X-Y-Z Max Travel：400mm x 400mm x 100mm
X-Y Dispensing Area：300mm x 300mm
Dimensions(mm)：770(W) x 785(D) x 810(H)
Robot Weight：~100 kg
XYZ Speed(mm/sec)：800, 800, 250mm/sec
XY Acceleration(mm/sec²)：0.25G, 0.25G
Repeatability(XYZ ±μm)：A:±5μm, B: ±10μm
Stream Vision Software :
Infinite nested recognitions
TemplateMatch-including(rotation)
Corner Finder
Dispenser Type
Counter Mode
Jet Mode
Channel Filter
ADVANCED VISION SOFTWARE
Integrating sophisticated motion control, vision alignment and AOI, K&S dispensing software V2K major features
include :
CAD file input and dispensing route auto editing and optimization
Fast global alignment for panelized PCB
Intuitive user interface for quick direct teaching
Vision algorithms and image filters for critical vision alignment
Synchronized dispensing and motion speed to ensure the consistent dispensing height at the start, the end and
the crossing point.
Automatic dispensing weight measurement and calibration
Fiducial on fly
Height detection on fly for 3D
Remote teaching
5 axis motion control on Z axis
Post dispensing AOI
