Depaneling
IPTE Depaneling systems are designed to singulate individual boards from a panel in a high speed, low stress
process. The depaneling units are economical in footprint, cost, have an excellent return on investment and
embrace all the latest concepts in lean design.
The welded steel framed unit is fully equipped with its own control and diagnostics via a user friendly
interface. Each unit is fully compatible with other SMEMA units and other standard equipment in electronics
manufacturing lines to ensure a truly ‘plug and play’ assembly line strategy. A large variety of routing is
possible: top or bottom, routing with saw, router bit and laser; each process type oers a robust solution to the
market.
In-line depaneling
SpeedRouter FlexRouter II
-
Linear motor technology
-
Bottom side routing
-
Ideal for high diversity, high volume production
-
Flexible servo and pneumatic grippers
-
Flexible outfeed handling (conveyor, flat belt, tray)
-
Bottom side dust cleaning
-
Robust aluminum cast and granite construction
-
Linear motor technology
-
Bottom side routing
-
Capable of routing and/or sawing
-
Product specific gripper for complete PCB
-
Flexible outfeed handling (conveyor, flat belt, tray)
-
Bottom side dust cleaning
&
PLUG & PLAY
&
PLUG & PLAY
Off-line depaneling
EasyRouter II
- High speed, low stress depaneling
-
Top side routing with high frequency spindle
-
Top or Bottom side dust cleaning
- Depaneling accuracy ±0,1 mm
-
Turntable concept for up to two fixtures
-
Loading/Unloading during depaneling process
-
Camera assisted teaching
-
Ionizer
-
High speed, low stress depaneling
-
Top side routing and/or sawing
-
Top or Bottom side dust cleaning
- Depaneling accuracy ±0,1 mm
-
Turntable concept for up to two fixtures
-
Loading/Unloading during depaneling process
-
Router bit breakage detection and life monitoring
-
Automatic router bit exchange
-
Ionizer
TopRouter
SLIMRouter
EasyRouter II Plug&Play
-
High speed, low stress depaneling
-
Top side routing with high frequency spindle
-
Top or Bottom side dust cleaning
- Depaneling accuracy ±0,1 mm
-
Turntable concept for up to two fixtures
-
Loading/Unloading during depaneling process
-
Camera assisted teaching
-
Ionizer
-
Plug and Play
-
High speed, low stress depaneling
-
Top side routing and dust cleaning
- Depaneling accuracy ±0,2 mm
-
Fixed configuration
-
Turntable concept
-
Loading/Unloading during depaneling process
-
Ionizer
-
Plug and Play
EasyRouter II SLIMRouter TopRouter
Dimensions (L x D x H): 1.080 x 1.630 x 1.300 mm 1.000 x 1.630 x 1.300 mm 1.000 x 1.900 x 1.840 mm
Working area: 425 x 365 mm (
*
) 400 x 350 mm (
*
) 435 x 370 mm (
*
)
Routing access: Top Top Top
Top side component clearance: 8 mm / 30 mm (
*
) 8 mm (
*
) 8 mm
Bottom side component clearance: 30 mm 8 mm 30 mm
PCB Loading/Unloading: Manual Front Manual Front Manual Front
Cutting tool: Router Router Router and/or Saw
Cutting speed router: max 60 mm/sec max 60 mm/sec max 60 mm/sec
Cutting speed saw: - - max 200 mm/sec
Depaneling accuracy: ± 0,1 mm ± 0,2 mm ± 0,1 mm
Router bit exchange: manual manual Auto Exchange 10 Bits (
*
)
Saw blade exchange: - - manual
Router bit break detection: standard standard standard
Plug and Play: option standard -
Ionisation: standard standard standard
Weight: 650 kg 600 kg 1.100 kg
Vacuum cleaner: option (external) option (external) option (external)
(
*
) Depending on conguration
Depaneling specification
In-Line Depaneling Equipment
FlexRouter II SpeedRouter
Dimensions (L x D x H): 1.000 x 2.200 x 2.000 mm 1.200 x 1.600 x 1.900 mm
Working area: 400 x 330 mm (
*
) 410 x 330 mm (
*
)
Routing access: Bottom Bottom
Top side component clearance: 50 mm 30 mm
Bottom side component clearance: 8 mm 8 mm
PCB Loading/Unloading: In-Line In-Line
Cutting tool: Router Router and/or Saw
Cutting speed router: max 60 mm/sec max 60 mm/sec
Cutting speed saw: - max 120 mm/sec
Depaneling accuracy: ± 0,1 mm ± 0,1 mm
Router bit exchange: manual, Option Auto 8 Bits Auto Exchange 25 Bits
Saw blade exchange: - manual
Tool break detection: option option
Ionisation: standard standard
Weight: 1.600 kg 1.400 kg
Vacuum cleaner: option (external) option (external)
(
*
) Depending on conguration
Off-Line Depaneling Equipment
