Delta 8
Selective Coating/Dispensing System
The Delta 8 is a exible robotic conformal coating/dispensing
system that is ideal for selective coating, potting, bead,
and meter-mix dispensing applications. Conceptualized for
maximum exibility, the system can also be congured for
custom assembly applications.
Maintaining the preferred features of previous workcells, the
Delta 8 features a robust overhead three-axis motion platform
suitable for inline or batch operations. Improved structural
and gantry rigidity have been added for robustness and easier
access.
The Delta 8 has many options and integrated
features including:
• Robotic system repeatability of 25 microns
• Patented servo-controlled optional four-axis motion
featuring valve tilt and rotate
• Closed loop process control throughout gantry system
• Multiple dispensing applications or materials in one cell
• Onboard PC for unlimited program storage
• Exclusive PathMaster® programming environment
For more information, please contact PVA at info@pva.net
or (518) 371-2684.
System Specications
Gantry System Design
Closed loop brushless DC servo motors
with optical encoders and ball screw slides
on all axes
Work Area
1 Valve / Tool:
621 mm x 595 mm x 100 mm
(24.45 in x 23.43 in x 3.94 in)
XYZ Repeatability
±25 microns (±0.001 in)
Resolution
5 microns (0.0002 in)
Maximum Acceleration
0.5g
Footprint
1046 mm x 1270 mm x 2350.9 mm
(41.18 in x 50.0 in x 92.56 in)
Programming Software
PathMaster® software with oine image
import and programming capability
One Mustang Drive | Cohoes, NY 12047
tel 518 371 2684 | fx 518 371 2688 | www.pva.net
PathMaster® is a registered trademark of Precision Valve & Automation, Inc.
Windows® is a registered trademark of Microsoft Corporation.
INNOVATION. PRECISION. EXCELLENCE.
Delta 8
The Delta 8 is ideal for selective conformal coating and dispensing applications that require a high level of accuracy and repeatability in moderate
to high volume manufacturing environments. It is a closed-loop robotic platform featuring optical encoder feedback on all axes.
Power 120V, 220V, 50-60 Hz Board Handling
Air Supply 80 psi dry, unlubricated air Conveyor Type: Flat belt or chain
Minimum Conveyor Width: 50 mm (1.97 in)
Maximum Conveyor Width: 500 mm (19.685 in)
XYZ Specications Board Clearance Topside: 100 mm (3.94 in)
Gantry System: Brushless DC servo motors Board Clearance Underside: 100 mm (3.94 in)
Precision ball screw slides Edge Clearance: 4.7 mm (0.185 in)
XYZ Repeatability: ±25 microns (±0.001 in)
Maximum Speed (XYZ): 670 mm/sec (27.6”/sec) Transport Height: 940 mm - 965 mm (37 in - 38 in)
Maximum Acceleration: 0.5g Communications Protocol: SMEMA
Conveyor Options: Lift and locate, through hole pin,
Resolution: 5 microns (0.0002 in) under board support
Conveyor Speed: Up to 24.4 m/min (80 ft/min)
Payload Capacity: 11.36kg (25 lbs) Process Flow: Programmable right to left or
left to right, bidirectional
Weight Limit: 5 pounds (belt)
Standard Features 15 pounds (chain)
PathMaster® Windows- based software
FastPath™ oine image programming capability
Onboard PC with at screen monitor Fluid Applicators
Remote teach pendant with trackball Spray Valves: FCS300-ES, FCS300-R/F, FC100-CF
USB communication port Dispense Valves: FC100-MC, FCM100, SB300
Closed-loop low level exhaust notication (spray systems) Jetting Valve: JDX
Auger Valves: SV200, SVX
Optional Features: Progressive Cavity Valves: VPK450, VPK-2K
Servo 4th Axis motion featuring valve tilt & rotate
Closed-loop material ow monitoring Material Feed Options: Syringe (1-55cc)
Inline material metering Cartridge feed (6-20 oz)
Bar code program selection Pressure vessel
Low level uid sensor Drums, totes
Valve and / or uid heating
Programming camera
Active vision with XY correction
Substrate heating – contact or non-contact Backside of Machine: 80 - 100 PSI dry compressed air required
Dispense zone weigh scale Minimum 300CFM exhaust required
Multi-zone conveyor
Conveyor auto width adjust Power drop required - See machine spec for voltage
1818 mm
71.57 in
2350.9 mm
92.56 in
Exhaust
4 in diameter
1270mm
50 in
1046 mm
41.18 in
