Application name Recommended application Recommended temperature Recommended time Capacity per shift Stencils 20 – 40°C 15 min. 32 2 INDIVIDUAL PROCESS CLEANING PARAMETERS highly recommended C D C CLEANING DRYING InJet ®…
Dimensions (w x l x h) 800 x 1280 x 1650 mm
Weight 250 kg
Ø energy consumption per 1 cycle 1,47 kWh
Cleaning uid consumption per 1 cycle 0,05 – 0,2 l
Compressed air consumption per 1 cycle 3 l / 5 Bar
Max. dimensions of the cleaned parts 190 x 860 x 790 mm
Exchangeable mechanical lter of cleaning uid 20 - 100 μm
Operating pressures cleaning: 1,0 Bar - 2,8 Bar
Cleaning uid ow rate 125 l/min
Temperature range setting of the cleaning uid From ambient temperature to 60°C
Temperature range setting of the drying From ambient temperature to 80°C
Noise level < 70 dB
Device control PLC + 4,6“ touchscreen
TECHNICAL PARAMETERS
Power supply 400 V, 50Hz (3+N+PE)
Power connection EU 32 A
Pmax 7.2 kW
Exhaust pipe diameter Ø 100 mm
Exhaust pipe capacity 380 m
3
/h
Volume of the storage tanks for cleaning 60 l
Service space required around the device 600 mm
Compressed air 6 mm
INSTALLATION REQUIREMENTS
www.dct.cleaning
InJet
®
388 CD TECHNICAL DATA SHEET
Application name Recommended
application
Recommended
temperature
Recommended
time
Capacity per
shift
Stencils 20 – 40°C 15 min. 32
2 INDIVIDUAL PROCESS
CLEANING PARAMETERS
highly recommended
C
D
C
CLEANING
DRYING
InJet
®
388 CD TECHNICAL DATA SHEET
D
www.dct.cleaning
1 process chamber fully automatic solution
PLC + 5,7" touchscreen
Uncontrolled rotation arms - 2 arm
Lockable travelling wheels
100% closed circuit
Cleaning uid heating
Hot air drying
Emergency stop button
Chimney ap with draft diverter
Pneumatic door lock
2 powerful hot air blowers
Electronic monitoring of the uid pressure
High capacity stainless steel lter housing - DCT utility design
100% Stainless steel design - 15 years warranty:
- Cleaning and drying distribution
- Process chamber
- Storage tanks
Designed for easy maintenance and servicing
Optimized stainless steel nozzles
Spare parts (base kit)
STANDARD EQUIPMENT
Controlled rotation arms – adjustable speed - 2 arms
Controlled rotation arms – adjustable speed - 3 arms
Additional drying technology – air knife
Fluid leakage tray - stainless steel
Status light
Acoustic signalization
Barcode reader DCT
OPTIONAL ACCESSORY - MANUFACTURING PART OF THE MACHINE
InJet
®
388 CD
TECHNICAL DATA SHEET
continued on next page
