MODEL:
SP600
SEMI-AUTOMATIC
STENCIL PRINTER
Unbeatable
Service
Worldwide
for you!
Specialist in small
and medium-sized
manufacturing.
All from
one hand.
Innovative
Features
Quality &
innovation at
a fair price.
Guiding setup of single- or double-si-
ded circuit boards. Stops ensure a
constant same positioning.
Align the PCB to the template using
adjustment screws on the X / Y / R axes
Dual-camera vision for fast PCB orientation*
Dual squeegees with dual-stroke control
for ecient solder paste use
Flexible mounting for single-
or double-sided boards*
Fast job setup and changeover
Parallel separation of stencil and PCB with
programmable speed control for well
dened prints
Print repeatablility:
+/- 0.01 mm
Stencil frame size:
350 x 350 mm bis 815 x 500 mm
Maximum PCB size:
650 x 370 mm
*optional
*We reserve the right to make changes without notice.
MODEL:
SP600
SEMI-AUTOMATIC
STENCIL PRINTER
SPEZIFICATIONEN
• Stencil frame size:
- 350 x 350 mm to 815 x 500 mm
• Working table size:
- 600 x 400 mm
• Maximum PCB size:
- 650 x 370 mm
• X-Axis range:
- +/- 15 mm
• Y-Axis range:
- +/- 12 mm
• Z-Axis range:
- 0 - 35 mm
• Theta rotation range:
- +/- 5°
• Underside Clearance:
- 25 mm
• Registration Repeatability:
- +/- 0.01 mm
• Overall dimensions:
- 1402 x 962 x 1001 mm (B x T x H)
• Machine weight:
- 108 kg
