Gener al F amil y H887 Pitch [mm/mil] 4 .0 / 157 Mechanical specifications Internal thread 3X 0 .35 Dimensions T otal length [mm] 19. 50 Outer diameter [mm] 3. 50 Collar height [mm] 0.20 Accessories …
General
Family H887
Pitch [mm/mil] 4.0 / 157
Mechanical specifications
Internal thread 3X0.35
Dimensions
Total length [mm] 19.50
Outer diameter [mm] 3.50
Collar height [mm] 0.20
Accessories
Order code 1031734
Family drawing
