LED tube placement Based on pro ven and truly scalable technology , the iX 502 1500 mm brings the ideal solution for high speed, high quality LED retrofit tube manuf acturing. In f act, because it is compatible with all e…
Services
Maintain your quality
Knowing your service requirements are unique, K&S tailors a service solution to
meet your changing needs. K&S is recognized as the industry’s premier service
provider.
Machine accuracy verification service is one of our services that guarantees the
quality of your equipment as long as you have it.
Assessment Services
Recommendations for guaranteed efficiency and yield improvements follow an on-site
assessment by K&S.
Start-up and Transition Support
• Training by certified trainers;
• Professional, fast installation; and
• Dedicated project management &
worry free transition service
Maximum component size
Maximum component height
Optional
Footprint (L x W)
Maximum tape feeding
positions (8 mm)
Maximum # of Tray
components
Maximum output
IPC 9850/9850A
45 x 45 mm (1.77 x 1.77")
15 mm (0.59")
21 mm (0.83")
4,890 x 1,844 mm (192.52 x 72.60")
211
422
2
145,300 placements per hour
120 x 52 mm (4.72 x 2.05")
25 mm (0.98")
50 mm (1.97")
6,060 x 1,844 mm (238.58 x 72.60")
292
583
32
152,300 placements per hour
17.5 x 17.5 mm (0.69 x 0.69")
10.5 mm (0.41")
12 mm (0.47")
3,720 x 1,705 mm (146.46 x 67.13")
130
260
2
104,000 placements per hour
T2
502 - LED FA ( 5)502 -
T2-H1
LED tube placement
Based on proven and truly scalable technology, the iX 502
1500 mm brings the ideal solution for high speed, high quality
LED retrofit tube manufacturing. In fact, because it is
compatible with all existing iX 502 features and options, it
offers so much more.
• Boards up to 1500 mm;
• Full LED Binning support;
• Full LED nozzle range; and
• Advanced LED placement process technology
LED Feature Alignment
Perfect optical performance of automotive head lights requires highly accurate
alignment of an LED’s light emitters. LED Feature Alignment on the high accuracy
Twin Placement Robot makes any automotive lighting challenge look like an easy
job. Ultimate flexibility combined with the best accuracy in the market.
Tall components
iFlex H1 now places tall connectors and other components.
This can enable to pull large components from manual
insertion and selective soldering into your reflow line.
Once again: we’re setting the industry standard for process
control in this application area.
Component range: 50 mm height components can be placed
on panels, with premounted components of 50 mm height.
OPTIONAL FEATURES
For sales, service and manufacturing locations, visit www.kns.com
© 2017 Kulicke & Soa Industries Inc. Specifications may change without notice.
The iFlex logo, iFlex, K&S logo, and Kulicke & Soa are trademarks of Kulicke & Soa Industries, Inc.
EA-001-08/2017
