253
31.2.NAMEPLATE, SEAL(WM)
31.2.銘板、シール(WM)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
1 DCWM0010 1 SEAL ｼｰﾙ PL
2 DCWM0110 1 NAMEPLATE, PRESSURE 銘板 圧力 PL
3 DCWM0040 3 SEAL ｼｰﾙ PL
4 DCWM0050 2 SEAL ｼｰﾙ PL
5 DCWM0060 1 NAMEPLATE, CAUTION 銘板 注意 PL
6 DCWM0071 1 SEAL, BAR CODE ｼｰﾙﾊﾞｰｺｰﾄﾞ PL
7 DCWM0081 1 SEAL, BAR CODE ｼｰﾙﾊﾞｰｺｰﾄﾞ PL
8 DCWM0091 2 SEAL, BAR CODE ｼｰﾙﾊﾞｰｺｰﾄﾞ PL (Option)
9 KPA0900 2 NAMEPLATE, CAUTION 銘板 注意 PL
10 KPA0920 2 NAMEPLATE, CAUTION 銘板 注意 PL
11 KPA0890 2 SEAL ｼｰﾙ PL
12 YWM0090 4 NAMEPLATE, CAUTION 銘板 注意 PL
14 WWM0210 SEAL ｼｰﾙ PL
95 DCUK0710 2 SEAL ｼｰﾙ PL
96 WWM0140 1 SEAL ｼｰﾙ PL
97 DGPZ5040 1 NAMEPLATE 銘板 PL CP-743E
98
DGWM0890
1
PLATE SEAL
ﾌﾟﾚ-ﾄ ｼ-ﾙ
PL
CP-743E PARTS LIST
252
253
31.3.NAMEPLATE,SEAL(WM)
31.3.銘板、シ−ル(WM)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
15 DCPH1140 1 SEAL ｼｰﾙ PL
16 EEBR2850 1 SEAL ｼｰﾙ PL
17 EEBR1870 1 SEAL ｼｰﾙ PL
18 EEBR1892 1 SEAL ｼｰﾙ PL
19 WWM0152 12 SEAL ｼｰﾙ PL
20 DCWM0100 2 SEAL ｼｰﾙ PL
21 CSWM0311 4 SEAL ｼｰﾙ PL
92 EEBR2840 3 SEAL ｼｰﾙ PL
93 EEBR2820 3 SEAL ｼｰﾙ PL
94 EEBR2830 3 SEAL ｼｰﾙ PL
99 DCWM0800 1 SEAL ｼｰﾙ PL
100 DCWM0770 1 SEAL ｼｰﾙ PL
101 DCWM0780 1 SEAL ｼｰﾙ PL
102 DGWM0900 2 SEAL ｼｰﾙ PL
103 DGWM0910 3 SEAL ｼｰﾙ PL
104 CSSS1340 1 SEAL ｼｰﾙ PL
105
CSSS1350
1
SEAL
ｼｰﾙ
PL
CP-743E PARTS LIST
254
