Safety
It is imperative to follow safety guidelines to prevent electric
shock, injury, fire or explosion.
- When using the support with a preheater unit, the temperature of accessible surfaces may remain high
after the unit is turned off. Handle with care.
- Be careful with the remains of liquid tin. In contact with the skin, it can cause burns.
- Avoid flux coming into contact with skin or eyes to prevent irritation.
- Be careful with the smoke produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when working
to avoid personal harm.
- This appliance can be used by children over the age of eight as well as persons with reduced
physical, sensory or mental capabilities or lacking experience provided that they have been given
adequate supervision or instruction concerning the use of the appliance and understand the hazards
involved. Children must not play with the appliance.
- Maintenance must not be carried out by children unless supervised.
Maintenance
Before carrying out maintenance or storage,
always allow the support to cool down.
- Check periodically that the Support is clean,
especially the sliding guide axes.
- Use a damp cloth when cleaning. Alcohol
can only be used to clean the metal parts
- Replace any defective or damaged piece.
Use original JBC spare parts only.
- Repairs should only be performed by a JBC
authorized technical service.
6
Sliding guide axes
clean periodically
Safety
It is imperative to follow safety guidelines to prevent electric
shock, injury, fire or explosion.
- When using the support with a preheater unit, the temperature of accessible surfaces may remain high
after the unit is turned off. Handle with care.
- Be careful with the remains of liquid tin. In contact with the skin, it can cause burns.
- Avoid flux coming into contact with skin or eyes to prevent irritation.
- Be careful with the smoke produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when working
to avoid personal harm.
- This appliance can be used by children over the age of eight as well as persons with reduced
physical, sensory or mental capabilities or lacking experience provided that they have been given
adequate supervision or instruction concerning the use of the appliance and understand the hazards
involved. Children must not play with the appliance.
- Maintenance must not be carried out by children unless supervised.
Maintenance
Before carrying out maintenance or storage,
always allow the support to cool down.
- Check periodically that the Support is clean,
especially the sliding guide axes.
- Use a damp cloth when cleaning. Alcohol
can only be used to clean the metal parts
- Replace any defective or damaged piece.
Use original JBC spare parts only.
- Repairs should only be performed by a JBC
authorized technical service.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
7
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
0026995-301123
Specifications
PHBS
Support for PCBs up to 36x28cm / 14x11”
Ref. PHB-SA
- Support Dimensions - Low Position: 432 x 514 x 78 mm
(L x W x H) 17 x 20.2 x 3.1 in
- Support Dimensions - High Position: 432 x 514 x 98 mm
(L x W x H) 17 x 20.2 x 3.9 in
- Max. PCB Dimensions (Between Clamps): 36 x 28 cm / 14 x 11 in
Thickness 6 mm / 0.236 in
- Total Net Weight: 2.80 kg / 6.17 lb
- Total Package Dimensions / Weight: 595 x 520 x 180 mm / 4.80kg
(L x W x H) 23.2 x 20.5 x 7.09 in / 10.58 lb
Complies with CE standards.
ESD safe.
