2 | www.veexinc.com
• Ethernet, Fiber Channel, SDH/SONET, PDH/DSn,
Datacom and G.703 64K Codirectional Testing
• SFP+ Optical Interface for 10GBASE-X,
100/1000BASE-X, SyncE, 1/2/4GFC, STM-0 to 64,
OC-1 to 192, IEEE C37.94
• RJ45 for 10/100/1000BASE-T
• Throughput, BERT, IPv4/IPv6, Loopbacks, NetWiz,
Ping, trace route, Scan, L2CP Transparency, Errors,
Alarms, Events, Delay, Test Prole Auto Scripting/Sequencer
• RFC2544 Throughput, latency, frame loss and back to back tests
• Layer 4+ test suite: V-TEST (speed test), V-FTP, RFC6349 V-PERF
upload & download tests
MTX150
Multi-Service Installation & Maintenance Test Set
• V-TEST Throughput Test supports VeEX Mode
and Speedtest Powered
TM
Mode based on Ookla
®
technology
• V-PERF, support of RFC6349
• SFP+ test interface for 100/1000BASE-X and
10GBASE-R
• Built-in RJ45 test interface with PHY for
10/100/1000BASE-T, 2.5GBASE-T, 5GBASE-T, 10GBASE-T
(no adapters required)
• NoApp
®
(US Patent 12,190,199) QR code capability for
faster result transfer
• Test Scheduling option via R-Server Proles to ensure a
stable and reliable network experience
MTX150x Advanced Features Only
• Dual SFP+ and Dual RJ45 test ports
• Dual-port testing capabilities
• Throughput, BERT, Loopback
• RFC2544 Throughput, latency, frame loss and
back-to-back tests
• 2.5G/5G/10GBASE-T via native RJ-45 port
Ethernet/Multi-Gig Internet Test Set
MTX150x/MTX150x Lite
• Complete Layer 4+ test suite: V-TEST (Ookla Speedtest),
V-PERF (RFC6349)
• Wi-Fi (802.11a/b/g/n/ac/ax) 2.4 GHz, 5 GHz and 6 GHz
scan, coverage verication and speed test.
• Built-in RJ45 test interface with PHY for 1000BASE-T,
2.5GBASE-T, 5GBASE-T, 10GBASE-T (no adapters required)
• SFP+ test interface for 100/1000BASE-X and 10GBASE-R
• NoApp QR code capability for faster result transfer
Multi-Gig Internet Services & Ethernet Speed Test Set
MTX90
• True 2x100GE concurrent testing
• 400G Ready via software option
• Native PAM4 hardware - no adapters required
• Full compatibility with QSFP-DD, QSFP56,
SFP-DD, and SFP56 transceivers, DACs, AOCs,
network equipment and 400GE links
• Broad range of supported 100GE and 400GE
interfaces: 100GELR4/LR1/FR1/DR1, 400GBASE-
SR8, FR8, LR8, DR4, FR4, LR4, CR8, CR4 and 400ZR/ZR+
• RJ45 interfaces supporting 10/100/1000BASE-T and
2.5G/5G/10GBASE
Dual 100G/Single 400G Portable Test Set
MTX640
• True 2x400GE concurrent testing
• Dual ports for all common pluggable optics
form factors (1G to 400GE)
• Native PAM4 hardware - no adapters required
• Full compatibility with QSFP-DD, QSFP56,
SFP-DD, and SFP56 transceivers, DACs, AOCs,
network equipment and 400GE links
• Broad range of supported 400GE interfaces:
400GBASE-SR8, FR8, LR8, DR4, FR4, LR4, CR8, CR4 and
400ZR/ZR+
• RJ45 interfaces supporting 10/100/1000BASE-T and
2.5G/5G/10GBASE
• Fiber Channel up to 32G and OTU4 support
Dual 400G Portable Test Set
MTX642
• CPRI: 614.4 Mbps to 12.164 Gbps (up to 24.330 Gbps with
TX300s-100GX
• OBSAI: 768 Mbps to 6.144 Gbps
• Ethernet: 10/100/100BASE-T, 2.5G/5G/10GBASE-T (via copper SFP+)
• Fiber Channel: 1/2/4/8/10/16G (up to 32G with TX300s-100GX)
• VeSion R-Server, VeExpress, EZ-Remote, Web Remote, VNC, SCPI
• LACP Testing 1G & 10G
• V-Perf (RFC6349) 1G, 10G, 25G, & 100G
• Up to four (4) independent test ports
• OTU4, OTU3, 100GE, 50GE, 40GE,
25GE options
• OTU1/2/1e/2e, ODU0, ODUex
• SONET/SDH up to OC-192/STM-64
• DSn/PDH: DS1, DS3, E1, E3, E4
• G.703 64k Codir & C37.94
The TX300s, with VeExpress license management, is a full-featured, eld-congurable portable test solution for Carrier Ethernet, Backhaul, Mobile and
Transport testing. This exible and multi-tasking platform supports Carrier Ethernet, OTN, SDH, SONET, PDH, DSn networks, and offers extensive support for
Mobile Backhaul technologies with SyncE, eCPRI and CPRI/OBSAI testing.
TX300s Series
Multi-Service Test Set with VeExpress
TX340s Dual Test Port Hardware OptionTX300s-100Gx Hardware OptionTX300s-OTDR Hardware Option
800/400/100G ETHERNET
3 | www.veexinc.com
800/400/100G ETHERNET
MPA-HD Chassis Highlights
• 3U x 19” rack mounted or benchtop chassis
• Supports up to 4 pluggable test modules
Scalable High Density Test Solutions - Up to 8x 800G or 16x 400/100G Test Ports per Chassis
MPA-HD & MPA-ONE
MPA-ONE Chassis Highlights
• 1U x 14” rack mounted or bench top chassis
• Supports 1 pluggable test module
Dual Port 800G Test Module with QSFP-DD800 Ports
MPM-HD-802
• 800GE, 400GE, 200GE, 100GE & Breakout applications
• OTN and FlexO applications
• 106G/53G PAM4 and 28G NRZ host lane support
Quad Port 400G Test Module with QSFP-DD & SFP-DD
Ports
MPM-HD-404
• 400GE, 200GE, 100GE, 50GE, 40GE, 25GE, 10/1GE & Breakout
applications
• 53G PAM4 and 28/10G NRZ host lane support
Dual Port 800G Test Module with OSFP800 Ports
MPM-HD-822
• 800GE, 400GE & Breakout applications
• OTN and FlexO applications
• 106G/53G PAM4 and 28G NRZ host lane support
Dual Port 400G Test Module with QSFP-DD & SFP-DD
Ports
MPM-HD-402
• 400GE, 200GE, 100GE, 50GE, 40GE, 25GE, 10/1GE & Breakout
applications
• 53G PAM4 and 28/10G NRZ host lane support
Dual Port 800G Test module with OSFP800-RHS Ports
MPM-HD-832
• 800GE, 400GE & Breakout applications
• OTN and FlexO applications
• 106G/53G PAM4 and 28G NRZ host lane support
Quad Port 100G Test Module with QSFP-DD & SFP-DD
Ports
MPM-HD-104
• 100GE, 50GE, 40GE, 25GE, 10/1GE & Breakout applications
• 400/200GE FEC/Throughput
• 53G PAM4 and 28/10G NRZ host lane support
Eight-Port 200G Test Module with SFP-DD112 Ports
MPM-HD-208
• 100GE, 50GE, 25GE, MACsec & Breakout applications
• 106G/53G PAM4 and 28G NRZ host lane support
Dual Port 100G Test Module with QSFP-DD & SFP-DD
Ports
MPM-HD-102
• 100GE, 50GE, 40GE, 25GE, 10/1GE & Breakout
applications
• 400/200GE FEC/Throughput
• 53G PAM4 and 28/10G NRZ host lane support
MPA Series Platform Highlights
• 800G to 10Mbps simultaneous and independent Multi-Port & Multi-
User testing
• Modular and eld-maintainable platforms designed for 24x7 operation
• Modern & intuitive HTML5 Web UI remote
• Test automation including Python API and SCPI CLI
• Pay-As-You-Go platform allowing test modules to easily be added on
site
MPA Series Test Applications
• Line-side and client-side interfaces
• ZR, OpenZR+ and OpenROADM pluggable DCO; LPO, LRO, AOC &
DAC
• High powered DCO plug & AOC/DAC interop and benchmarking
• Ethernet/IP, OTN, SDH/SONET and Fiber Channel interfaces
• FEC/PCS, MAC/Ethernet/IP throughput, RFC2544, & SDT
• Mulit-lane unframed BERT, PRBSQ, PAM4 and NRZ pattern testing
Multi-Port Test Solutions MPA
®
Series
With the rapid expansion of high-speed, high-availability networks, test and verication solutions must evolve just as quickly.
Not all 800G, 400G, and 100G T&M applications are alike - core, data center and lab environments each demand the right mix
of scalability, power, and automation.
The Multi-Port Analyzer (MPA) series are advanced packet optical transport trafc generation and analysis platforms specically
designed for the testing challenges of NEMs R&D, SVT, production and interoperability lab environments.
MPA
®
Multi-Port Analyzer
800/400/100G ETHERNET
The MPA Multi-Port Analyzer is an advanced packet optical transport trafc generation and analysis platform specically designed
for the demands of R&D, SVT, and manufacturing testing environments. The MPA provides simultaneous independent multi-port
testing from 1G to 400G for Ethernet/IP, OTN & SDH/SONET and Fiber Channel.
Platform Highlights
• Compact 1U x 19” rack mounted or benchtop chassis
• Supports up to 6x pluggable test modules
Dual Port 400G Test Module with CFP2-DCO and
QSFP-DD Test Ports
MPM-400DCO
™
• 400G CFP2-DCO and QSFP-DD dual port
testing
• 400GE, 200GE, 4x100GE, 100GE, 8x50GE,
50GE, 4x25GE, 4x10GE & OTU4
• FlexE 400GE, 200GE, 100GE QSFP PHY testing with
client up to 400G
• 400/200/100G FlexO options
Dual Port 400GE Test Module with QSFP-DD,
QSFP56 & SFP56 Ports
• 2x QSFP-DD, 2x QSFP56 & 2x SFP56 ports
• Dual port 400GE, 200GE, 4x100GE, 100GE,
50GE, 4x25GE, 25GE, 4x10GE, 10GE &
OTU4; Single Port 8x50GE
• FlexE 400GE, 200GE, 100GE QSFP PHY testing with
client up to 400G
• 400/200/100G FlexO options
MPM-400AR
™
100GE Test Module with QSFP28 and Dual SFP28 Ports
• 100GE, 100GE KR RS-FEC & 40GE
• Dual port 10/25/25G RS-FEC
• OTUCn (n=1-6), OTU4, OTU3, OTU3e1, & OTU3e2
• Dual port OTU2, OTU2e & OTU1e
• STL256.4 STM256/OC768
• Dual Port 10/16/32G Fiber Channel
MPM-100AR
Multi-Port 400G to 10 Mbps Testing
Supported Test Interface (Ports) MPM-HD-832 MPM-HD-822 MPM-HD-802 MPM-HD-208 MPM-HD-404 MPM-HD-402 MPM-HD-104 MPM-HD-102
OSFP800-RHS 2
OSFP800-IHS 2
QSFP-DD800 2
QSFP-DD
4 2 4 2
SFP-DD112 8
SFP-DD 4 2 4 2
Supported Test Interface (Ports) MPM-400DCO MPM-400AR MPM-600G MPM-100AR MPM-10G
CFP2-DCO 1
QSFP-DD 1 2
QSFP-56 2
QSFP28 6 1
SFP56 2
SFP28 2
SFP+ 2
Dual Port 10G Test Module with SFP+ Ports
• 10GE, 1GE, 100M, 2500BASE-X,
10M/100M/1000M/10GBASE-T Ethernet
• OTU1, OTU2, OTU1e, OTU2e, OTU1f, OTU2f;
SDH STM0/1/4/16/64 & SONET OC1/3/12/48/192
• Fiber Channel 1/2/4/8/10G
MPM-10G
6 Port 100G Test Module with QSFP28 Ports
MPM-600G
• 100GE, 100GE KR RS-FEC & 40GE
• OTUCn (n=1-6), OTU4, OTU3, OTU3e1, &
OTU3e2
• FlexE testing using 1 to 4 100GE QSFP28 PHYs with client rate to
400G; shim/calendar overhead, and MAC layer control/testing
