1 / 4 機種( M / C TY P E) ユニット( U N I T ) 発行日 I P ・Q P 2 モータフィーダ( M O TO R FEE D ER ) 0 0 . 1 0 . 2 7 形式( TY P E) 図番( D W G N o . ) S/ N W 5 6 エンボス( E M B O S S) ( A K D H A 7 1 * * ) K D E‑…
4/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/N
W56 エンボス( EMBOSS) ( AKDHA61**) KDE‑ 5600‑ 000681〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
76 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5255T 3 M3x6
77 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5289A 2 M4x12
78 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1022A 6 4M/M
79 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357M 13 M3x6
80 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5256A 4 M3x8
81 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1021A 15 3M/ M
82 ｺﾈｼﾞ SCREW K5168L 2 M2. 5x10 ﾊﾞｲﾝﾄﾞ ｺﾈｼﾞ
83 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1042A 2 4W‑ 3
84 ﾅｯﾄ 6ｶｸ NUT, HEX N1076A 11 M3 P=0. 5
85 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359A 2 M4x6
86 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357T 5 M3x8
88 ﾅｯﾄ 6ｶｸ NUT, HEX N1075A 2 M2. 5
89 ﾅｯﾄ 6ｶｸ NUT, HEX N1080A 4 M4
90 ｻｰｸﾘｯﾌﾟ CI R‑ CLI P S1021A 1 STｰEWｰ3
91 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357G 2 M3x4
92 ﾜｯｼｬ ﾋﾗ WASHER FLAT W1041A 3 M4
94 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K52565 1 M4x6
95 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5358A 6 M3x10
96 ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
97 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5273A 1 M3x5
99 ｼｰﾄ SHEET KHEM1081 1
100 ｼｰﾙ SEAL BFCH0160 1
101 ｽﾄｯﾊﾟ STOPPER KDFC0280 1
102 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1039D 2 M2× 0. 3× 5( ﾐｶﾞｷ丸）
103 ｼｰﾄ SHEET KDCC1280 1
104 SW SW S3087S 1
105 ﾜｯｼｬ ﾋﾗ WASHER，FLAT W1039H 2 M2. 5
106 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5277A 8 M3X12
107 ﾜｯｼｬ ｻﾗ WASHER，CONI CAL W1010A 6 M‑ 3‑ L
108 ｶﾊﾞｰ COVER KDCC1221 1
109 ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K51757 2 M2. 5x6
110 ﾜｯｼｬ ﾋﾗ WASHER，FLAT W1040A 5 M3
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
1/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/N
W56 エンボス( EMBOSS) ( AKDHA71**) KDE‑ 5600‑ 000681〜
番号
品名 図番 個数
No. Dwg. No. QTY
1 ﾎﾝﾀｲ BODY AKDHC6502 1
ﾎﾝﾀｲ BODY KDHC0713 1
ﾍﾞｱﾘﾝｸﾞ ﾐﾆｭﾁｭｱ BEARI NG, MI NI ATURE H4443A 1 LF‑ 850ZZ ( NMB)
ﾍﾞｱﾘﾝｸﾞ ﾐﾆｭﾁｭｱ BEARI NG, MI NI ATURE H4450A 2 LF‑ 1480ZZ( NMB)
ﾋﾟﾝ ﾍｲｺｳ PI N, PARALLEL H2092F 4 A4x10SUS303
2 ｵｻｴ RETAI NER KDHC0470 1
3 ｵｻｴ ﾘｰﾙ RETAI NER, REEL AKDHC6021 1
ｵｻｴ ﾘｰﾙ RETAI NER, REEL KDHC0030 1
ﾌﾟﾚｰﾄ PLATE KDCC0160 1
4 ｼｬﾌﾄ SHAFT AKDFC6037 1
ｼｬﾌﾄ SHAFT KDFC0095 1
ﾋﾟﾝ ｲﾁｷﾞﾒ PI N, LOCATI NG KDFC0201 1
ｽﾌﾟﾛｹｯﾄ SPROCKET KCAC0241 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
5 ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDCC1311 1
6 ｷﾞﾔ GEAR AKDDC6073 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0551 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDDC0152 1
ｼｬﾌﾄ ﾌﾟｰﾘ SHAFT, PULLEY KDDC0160 1
ｷﾞﾔ GEAR KCBC0401 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
7 ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR AKDDC6513 1
ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDDC0733 1
ｽﾍﾟｰｻ SPACER KCBC0160 1
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ BEARI NG, MI NI ATURE H4569A 1 LFｰ630ZZ ( NMB)
ﾋﾟﾝ ｼﾃﾝ PI N, PI VOT KDDC0210 1
8 ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ MOTOR, STEPPI NG AKDCC6072 1
ｶﾗｰ COLLAR KCAC0270 1
ｷﾞﾔ ﾋﾟﾆｵﾝ GEAR, PI NI ON KCAC0470 1
ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ MOTOR, STEPPI NG KDCC1400 1
9 ｶﾊﾞｰ COVER AKDCC6122 1
ｶﾊﾞｰ COVER KDCC0571 1
ｶﾊﾞｰ COVER KDCC0581 1
10 ﾘｰﾙ REEL AKDHC6510 1
ﾘｰﾙ REEL KDHC0820 1
ﾏｸﾞﾈｯﾄ MAGNET M1003X 5 丸型ﾈｵｼﾞ磁石φ 5x5
備考
Remarks
Descri pt i on
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
2/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/N
W56 エンボス( EMBOSS) ( AKDHA71**) KDE‑ 5600‑ 000681〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
11 ｶﾊﾞｰ COVER KDCC1370 1
12 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE AKDCC6531 1
ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDCC0821 1
ﾋﾟﾝ ｼﾃﾝ PI N, PI VOT KCAC0420 2
13 ｼｬﾌﾄ SHAFT AKDHC6035 1
ｼｬﾌﾄ SHAFT KDHC0074 1
ﾋﾟﾝ ｲﾁｷﾞﾒ PI N, LOCATI NG KDFC0201 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDDC0141 1
ｽﾌﾟﾛｹｯﾄ SPROCKET KCAC0241 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K51757 3 M2. 5x6
ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ WASHER , SPRI NG W1020H 3 M2. 5
14 ｶﾞｲﾄﾞﾃｰﾌﾟ GUI DE, TAPE KDHC0041 1
15 ｼｬﾌﾄ SHAFT KDHC0054 3
16 ﾛｰﾗ ROLLER KDHC0061 2
17 ｽﾌﾟﾘﾝｸﾞ SPRI NG KDCC0100 1
18 ﾜｯｼｬ WASHER KDCC0111 3
19 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDCC0124 1
20 ｵｻｴ ﾍﾞｱﾘﾝｸﾞ RETAI NER, BEARI NG KDCC0132 1
21 ﾌﾟﾚｰﾄ PLATE KDCC0742 1
22 ﾌﾟﾚｰﾄ PLATE AKDCC6550 1
ﾌﾟﾚｰﾄ PLATE KDCC1420 1
ﾌﾟﾚｰﾄ PLATE KDCC1340 1
23 ﾚﾊﾞｰ LEVER KDCC0190 1
24 ﾋﾟﾝ PI N KDCC0201 1
25 ｽﾍﾟｰｻ SPACER KDCC0231 4
26 ﾌﾟﾚｰﾄ PLATE KDCC0251 1
27 ﾋﾟﾝ PI N KDFC0103 1
28 ﾛｰﾗ ROLLER KDHC0091 1
29 ﾘｰﾙ REEL KDFC0113 1
30 ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0561 1
31 ﾋﾟﾝ PI N KDCC0321 1
32 ﾋﾟﾝ PI N KDDC0171 2
33 ﾛｰﾗ ROLLER KDDC0180 1
34 ｽﾌﾟﾘﾝｸﾞ SPRI NG KDDC0250 1
35 ｶﾊﾞｰ COVER KDCC0732 1
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
