9
DEK NeoHorizon 01iX
Machine Standard Configuration
Services
Specification
Voltage
100 Volts to 240 Volts ±10%. Single phase 50/60 Hz
Maximum Current at 115V
15 Amps with vacuum pump
6 Amps without vacuum pump
Maximum Current at 230V
8 Amps with vacuum pump
3 Amps without vacuum pump
Over Current Protection
An external circuit breaker ≤20 Amps is required to be fitted in
line with the machine supply
Air Supply
To ISO 8573.1 Standard Quality Class 2.3.3
Pressure 5 bar to 8 bar
General usage 5 litres/minute at 5 bar to 8 bar
Maximum usage 226 litres/minute at 6 bar
Shipping Information
Specification
Approximate Weight
862kg boxed (dependent upon configured options
selected with machine)
712kg unboxed (dependent upon configured options
selected with machine)
Approximate Dimensions
2080mm x 1500mm x 1590mm High
(81.9” x 59” x 62.6”) Boxed
Certification
Specification
CE
98/37/EC
89/336/EEC
73/23/EEC
Subsequent amendments
Acoustic Noise Level
Less than 70dB 2003/1/EC
10
DEK NeoHorizon 01iX
Machine Productivity Options
Process
Specification
Print Method
Paste Dispenser
Paste Roll Height Monitor
ProFlow® ATx
Stinger
Printing Environment Control
Temperature – Temperature Control Module (TCM)
Recommended Stencil Frame
VectorGuard
Adjustable Width Stencil Mount (AWSM)
Frame variants – Fully adjustable to accommodate
frame sizes in the range of 381mm to 736mm (15” to
29”) by 38mm height.
Image position: Centre / Front / Custom
Handling & Cleaner Options
Specification
Substrate Handling Size (maximum)
620mm (X) x 508.5mm (Y) – Long Board Option
Under Stencil Cleaning
Typhoon Under Stencil Cleaner (620mm, poly blade
insert only)
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Singulation
Software & Communications
GEM on TCP/IP
Statistical Process Control
On board, reported via operator interface (QC-CALC)
11
DEK NeoHorizon 01iX
Machine Productivity Options
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cups
Grid-Lok® tooling
Substrate Transport
Single piece conveyor with 3mm round belts
Single piece conveyor with flat belts (heavy boards)
Remote board stop (for use with heavy board option)
Substrate Fixture
All Purpose Clamping (APC) system*
Snuggers (edge clamping)
Foil-less clamps
* Can only be used with Modular single stage rail system – for availability contact product manager
Vision & Verification
Specification
HawkEye®
HawkEye® Bridging
Data Capture
Specification
Product Data Capture
Verification & Traceability
ProDEK closed loop
Camera Barcode Reader
