TS1201 Pinch Tube Pen
Item
Part Number
Description
3*
1201-000-004PK
Pinch Tube, Clear PE, Male to Female, 0.1'' (2.54mm) ID
3*
1201-000-004BPK
Pinch Tube, Black PE, Male to Female, 0.1'' (2.54mm) ID
3*
1201-000-006PK
Pinch Tube, Clear PE, Male to Female, 0.07'' (1.78mm) ID
3*
1201-006-000PK
Pinch Tube, Clear PU, Male to Female, 0.125'' (3.18mm) ID
Item
Part Number
Description
Item
Part Number
1
1201-000-002
Trigger, Handle
5
TSD1123-15
2
TSD1150-7
Spring
6
1201-000-001
3
SEE CHART
Pinch Tube
7
1201-000-003
4
1212-000-005
Pinch Cushion
Lubrication: No lubrication required on valve.
