TH3000i : Tray-Based Vision Solutions
The TH3000i is designed with advanced key technologies to provide high speed, high accuracy, one stop vision
inspection solutions specially catered for BGA, QFP, QFN, CSP, TSSOP, MSOP, SOP packages handled in tray.
TH3000i
Package
Inspected
BGA, QFP, QFN, CSP, TSSOP, MSOP, SOP
Package
Size
2mm x 2mm (Tray to Tray) to 120mm x 120mm
Handling
Mechanism
Tray to Tray
UPH Up to 60K (tray to tray)
Pick-up
Heads
1 x 14 (2x14 Optional)
Vision
Inspection
3D vision inspection, Leaded Packages Inspection, Ball Packages Inspection, Leadless Packages Inspection, Top 3D POP
Inspection, 2D Barcode Inspection, Mark Inspection, Package Vision Inspection, Passive Component Inspection, 6S Color
Inspection
Machine
Dimensions
(mm)
1935(H) x 1740(W) x 2330(L)
