5 Product data sheet Connections and Schema XUK2APANM12R Wiring Schemes M12 Connector 1 : (+) 3 : (-) 4 : OUT/Output PNP Outputs
4
Product data sheet
Mounting and Clearance
XUK2APANM12R
Mounting and Clearance
Possible Orientation of Elbowed Connector
5
Product data sheet
Connections and Schema
XUK2APANM12R
Wiring Schemes
M12 Connector
1 : (+)
3 : (-)
4 : OUT/Output
PNP Outputs
6
Product data sheet
Performance Curves
XUK2APANM12R
Detection Curves
