Gener al F amil y H7 56 Pitch [mm/mil] 2.54 / 100 Mechanical specifications Internal thread 1.6 Dimensions T otal length [mm] 40. 00 Outer diameter [mm] 2.00 Collar height [mm] 0.20 Accessories T ool for r eceptacle F A …
General
Family H756
Pitch [mm/mil] 2.54 / 100
Mechanical specifications
Internal thread 1.6
Dimensions
Total length [mm] 40.00
Outer diameter [mm] 2.00
Collar height [mm] 0.20
Accessories
Tool for receptacle FAWZ756
Twist-Proof Probes
Order code 1019498
Family drawing
All measurements are in mm.
